Nexperia USA Inc. 74HC9115D-Q100J
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $3.33 | $3.33 |
| 15+ | $0.76 | $11.40 |
| 25+ | $0.75 | $18.75 |
| 50+ | $0.71 | $35.50 |
| 100+ | $0.62 | $62.00 |
| N+ | $0.12 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Nexperia USA Inc. |
| Product Series | 74HC |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 9 |
| Number of Bits per Element | 1 |
| Input Type | Schmitt Trigger |
| Output Type | Open Drain |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Voltage - Supply | 2V ~ 6V |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SO |
| ROHS |  |
The 74HC9115D-Q100J from Nexperia is a 9-channel non-inverting buffer with open-drain outputs, part of the 74HC high-speed CMOS family. It operates from 2V to 6V and provides 5.2mA sink current per channel. The 20-SOIC package is suitable for surface-mount designs. It is ideal for wired-OR logic, level shifting, and driving LEDs or relays in automotive and industrial applications.
- 9 Channels: Provides multiple buffered outputs in a single package, saving space.
- Open-Drain Outputs: Enables wired-OR logic and level shifting to higher voltages.
- Wide 2V to 6V Supply: Compatible with 3.3V and 5V systems, simplifying design.
- Automotive Qualified (Q100): Meets AEC-Q100 standards for automotive reliability.
Wired-OR Logic
Use the 74HC9115D-Q100J to implement wired-OR connections. The open-drain outputs allow multiple devices to share a common line, ideal for interrupt or status signals.
Level Shifting to Higher Voltages
Shift signals from 3.3V logic to 5V or higher. The open-drain outputs can pull up to external voltages, enabling easy level translation.
LED and Relay Driving
Drive LEDs or relays directly. The open-drain outputs can sink current from an external supply, simplifying driver circuits.
I2C and SMBus Interfacing
Interface with I2C or SMBus lines. The open-drain outputs are perfect for bidirectional bus communication.
Automotive ECU Signal Buffering
In automotive ECUs, buffer sensor signals. The wide 2V to 6V range and -40°C to 125°C temperature rating ensure reliable operation.
Industrial Control Logic
Use in industrial controllers for signal distribution. The 9 channels provide ample buffering for multiple control lines.
- Q: What logic family does the 74HC9115D-Q100J belong to?
- A: It belongs to the 74HC family, which is high-speed CMOS logic.
- Q: What is the function of this IC?
- A: It is a 9-channel non-inverting buffer with open-drain outputs.
- Q: How many channels does it have?
- A: It has 9 channels, providing multiple buffered outputs.
- Q: What is the output type?
- A: The outputs are open-drain, allowing wired-OR connections and level shifting.
- Q: What is the voltage range?
- A: It operates from 2V to 6V, making it versatile for various supply levels.
- Q: What package is available?
- A: It comes in a 20-SOIC (0.295", 7.50mm Width) package.
