Analog Devices Inc. AD7653ACPZRL
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $95.60 | $95.60 |
| 15+ | $21.99 | $329.85 |
| 25+ | $21.51 | $537.75 |
| 50+ | $20.32 | $1,016.00 |
| 100+ | $17.93 | $1,793.00 |
| N+ | $3.59 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | PulSAR® |
| Packaging | Marketplace | Tape & Reel (TR) |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 1M |
| Number of Inputs | 1 |
| Input Type | Pseudo-Differential |
| Data Interface | SPI, Parallel, DSP |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 48-VFQFN Exposed Pad, CSP |
| Supplier Device Package | 48-LFCSP-VQ (7x7) |
| ROHS |  |
The AD7653ACPZRL is a precision 16-bit ADC from Analog Devices, designed for high-accuracy signal conversion. It offers a sampling rate of 1 MSPS, balancing speed and precision. With a single input channel and multiple interface options (SPI, parallel, DSP), it provides design flexibility for various microcontroller and DSP platforms. The device supports both external and internal references. Housed in a compact 48-VFQFN package, it operates over the industrial temperature range, making it ideal for medical, industrial, and scientific applications.
- High Resolution: 16-bit output provides exceptional accuracy for precision measurement applications.
- Multiple Interfaces: SPI, parallel, and DSP compatibility ensure easy integration with various digital systems.
- Wide Temperature Range: -40°C to +85°C operation suits industrial and automotive environments.
- Compact Package: 48-VFQFN CSP saves board space in dense designs.
Precision Data Acquisition
The AD7653ACPZRL's 16-bit resolution and 1 MSPS sampling rate enable high-accuracy digitization of sensor signals in industrial data loggers and analyzers.
Medical Instrumentation
High resolution is critical for ECG, EEG, and patient monitoring devices, ensuring accurate detection of subtle physiological signals.
Automotive Test Systems
With -40°C to +85°C operation, it is suitable for engine control unit (ECU) testing and battery characterization in automotive R&D.
Scientific Research
In spectroscopy and chromatography, the 16-bit resolution provides the dynamic range needed to resolve small peaks in complex samples.
Industrial Automation
The multiple interface options (SPI/Parallel/DSP) allow easy connection to PLCs and industrial controllers for precise process monitoring.
Energy Management
It can digitize current and voltage signals in smart grid meters, providing high-resolution data for accurate energy billing.
- Q: What is the AD7653ACPZRL?
- A: It is a 16-bit, single-channel, high-speed, low-power analog-to-digital converter (ADC) from Analog Devices.
- Q: What is the resolution?
- A: The resolution is 16 bits, providing 65536 discrete levels for high-precision measurements.
- Q: What is the sampling rate?
- A: The maximum sampling rate is 1 MSPS (mega-sample per second).
- Q: How many channels does it have?
- A: It has 1 input channel.
- Q: What interfaces are supported?
- A: It supports SPI, parallel, and DSP-compatible interfaces for flexible system integration.
- Q: What is the package type?
- A: It is available in a 48-VFQFN exposed pad package (CSP).
