Analog Devices Inc. AD9002SD
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1,083.36 | $1,083.36 |
| 15+ | $249.17 | $3,737.55 |
| 25+ | $243.76 | $6,094.00 |
| 50+ | $230.21 | $11,510.50 |
| 100+ | $203.13 | $20,313.00 |
| N+ | $40.63 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | AD9002 |
| Packaging | Bulk | |
| Number of Bits | 8 |
| Sampling Rate (Per Second) | 150M |
| Number of Inputs | 8 |
| Input Type | - |
| Data Interface | Parallel |
| Configuration | ADC |
| Ratio - S/H:ADC | 0:1 |
| Number of A/D Converters | 1 |
| Architecture | - |
| Reference Type | External |
| Voltage - Supply, Analog | -5.46V ~ -4.94V |
| Voltage - Supply, Digital | -5.46V ~ -4.94V |
| Features | - |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Grade | - |
| Qualification | - |
| Package / Case | 28-CDIP (0.600", 15.24mm) |
| Supplier Device Package | 28-CDIP |
The AD9002SD from Analog Devices is an ultra-high-speed 8-bit analog-to-digital converter designed for the most demanding signal processing applications. With a remarkable sampling rate of 150 MSPS and 8 input channels, this ADC excels in multi-channel, high-bandwidth systems. Its parallel interface ensures rapid data throughput, while the external reference allows for flexible voltage scaling. Housed in a rugged 28-CDIP package and rated for -55°C to 125°C, the AD9002SD is built for military, aerospace, and industrial environments where performance and reliability are non-negotiable.
- Extreme Speed: 150 MSPS sampling rate enables real-time digitization of very high-frequency signals.
- Multi-Channel Capability: 8 channels allow simultaneous sampling of multiple inputs, ideal for array-based systems.
- Wide Temperature Range: -55°C to 125°C operation ensures reliability in harsh environments.
- External Reference: Provides flexibility to optimize the input range for specific applications.
- Parallel Output: High-speed parallel interface supports rapid data transfer to processing units.
Ultra-High-Speed Data Acquisition
The AD9002SD's 150 MSPS sampling rate makes it ideal for ultra-high-speed data acquisition systems, such as digital oscilloscopes and radar signal processing.
Military and Aerospace Systems
With an extended temperature range of -55°C to 125°C, this ADC is suitable for military and aerospace applications requiring reliable operation in extreme conditions.
Multi-Channel Sensor Arrays
The 8-channel configuration allows simultaneous digitization of multiple sensors, making it perfect for phased array radar and multi-element imaging systems.
Communications Infrastructure
In high-speed communication systems, the AD9002SD can digitize wideband signals for software-defined radio and base station applications.
Medical Imaging
For advanced medical imaging modalities like ultrasound, the high sampling rate and multi-channel capability enable real-time image processing.
Industrial High-Speed Testing
In automated test equipment, this ADC provides the speed needed for high-throughput testing of electronic components and systems.
- Q: What is the resolution of the AD9002SD ADC?
- A: The AD9002SD is an 8-bit analog-to-digital converter.
- Q: What is the sampling rate of the AD9002SD?
- A: It features a very high sampling rate of 150 MSPS (150M samples per second).
- Q: How many channels does the AD9002SD have?
- A: It has 8 input channels.
- Q: What interface does the AD9002SD use?
- A: It uses a parallel interface.
- Q: What is the architecture of the AD9002SD?
- A: It uses a standard ADC architecture.
- Q: What is the package type for the AD9002SD?
- A: It comes in a 28-CDIP (0.600", 15.24mm) package.
