Analog Devices Inc. AD9012TQ
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1,083.36 | $1,083.36 |
| 15+ | $249.17 | $3,737.55 |
| 25+ | $243.76 | $6,094.00 |
| 50+ | $230.21 | $11,510.50 |
| 100+ | $203.13 | $20,313.00 |
| N+ | $40.63 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | AD9012 |
| Packaging | Bulk | |
| Number of Bits | 8 |
| Sampling Rate (Per Second) | 100M |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | - |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | - |
| Reference Type | - |
| Voltage - Supply, Analog | -5.46V ~ -4.94V, 4.75V ~ 5.25V |
| Voltage - Supply, Digital | -5.46V ~ -4.94V, 4.75V ~ 5.25V |
| Features | - |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Grade | - |
| Qualification | - |
| Package / Case | 28-CDIP (0.600", 15.24mm) |
| Supplier Device Package | 28-CDIP |
The AD9012TQ from Analog Devices is a high-speed 8-bit analog-to-digital converter engineered for applications requiring fast and reliable signal conversion. With a sampling rate of 100 MSPS and a single input channel, this ADC delivers excellent performance for high-frequency signal digitization. Its sample-and-hold architecture ensures accurate sampling, while the robust 28-CDIP package and wide temperature range make it suitable for military and industrial environments. The AD9012TQ is an ideal choice for radar, communications, and test equipment.
- High Sampling Rate: 100 MSPS enables real-time conversion of fast analog signals.
- Wide Operating Temperature: -55°C to 125°C ensures reliable operation in extreme conditions.
- S/H Architecture: Sample-and-hold circuitry improves accuracy for high-frequency inputs.
- Single Channel Simplicity: Dedicated single-channel design simplifies system integration.
- Durable Package: 28-CDIP package provides robust mechanical protection.
High-Speed Signal Processing
The AD9012TQ's 100 MSPS sampling rate makes it ideal for high-speed signal processing in applications like digital receivers and radar systems.
Military Electronics
With its wide temperature range of -55°C to 125°C, this ADC is well-suited for military electronics requiring dependable performance in extreme conditions.
Test and Measurement
In high-frequency test equipment, the AD9012TQ provides the speed and accuracy needed for capturing fast transient signals.
Communications Systems
For broadband communication systems, this ADC enables digitization of IF signals with high fidelity, supporting advanced modulation schemes.
Industrial High-Speed Control
In industrial applications requiring fast feedback loops, the AD9012TQ's high sampling rate ensures responsive and accurate control.
Scientific Instrumentation
For physics experiments and particle detection, the AD9012TQ offers the high-speed conversion necessary for capturing rapid events.
- Q: What is the resolution of the AD9012TQ ADC?
- A: The AD9012TQ is an 8-bit analog-to-digital converter.
- Q: What is the sampling rate of the AD9012TQ?
- A: It has a sampling rate of 100 MSPS (100M samples per second).
- Q: How many channels does the AD9012TQ have?
- A: It has a single input channel (1 channel).
- Q: What is the architecture of the AD9012TQ?
- A: It uses a sample-and-hold ADC (S/H-ADC) architecture.
- Q: What is the temperature range of the AD9012TQ?
- A: It operates over a temperature range of -55°C to 125°C.
- Q: What is the package type for the AD9012TQ?
- A: It comes in a 28-CDIP (0.600", 15.24mm) package.
