National Semiconductor ADC0820CCMSA
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $18.48 | $18.48 |
| 15+ | $4.25 | $63.75 |
| 25+ | $4.16 | $104.00 |
| 50+ | $3.93 | $196.50 |
| 100+ | $3.47 | $347.00 |
| N+ | $0.69 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | National Semiconductor |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 8 |
| Sampling Rate (Per Second) | - |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 2 |
| Architecture | Flash |
| Reference Type | External |
| Voltage - Supply, Analog | 4.5V ~ 8V |
| Voltage - Supply, Digital | 4.5V ~ 8V |
| Features | - |
| Operating Temperature | - |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 20-SSOP (0.209", 5.30mm Width) |
| Supplier Device Package | 20-SSOP |
The ADC0820CCMSA from National Semiconductor is an 8-bit analog-to-digital converter with a parallel interface. It features a single input channel and uses a Sample-and-Hold architecture for accurate conversion. This ADC is designed for general-purpose data acquisition and control applications, offering a straightforward interface for easy integration with digital systems.
- Simple Parallel Interface: Easy to connect to standard digital logic and microprocessors.
- Sample-and-Hold Architecture: Ensures accurate conversion of varying analog signals.
- Compact SSOP Package: Saves board space in dense designs.
- Proven Technology: From National Semiconductor, a trusted name in analog ICs.
Embedded Control Systems
The parallel interface simplifies connection to microcontrollers, making it suitable for embedded control and monitoring applications.
Data Logging Systems
Its 8-bit resolution is adequate for logging sensor data in industrial and environmental monitoring systems.
Battery Management
Can be used to monitor voltage and current levels in battery-powered devices, ensuring safe operation.
Motor Control
Provides feedback for current sensing in motor control loops, enabling precise speed and torque regulation.
Simple Instrumentation
Suitable for low-cost digital multimeters and panel meters where moderate accuracy is required.
Educational Kits
Its simple parallel interface makes it ideal for teaching ADC principles in university labs.
- Q: What is the resolution of the ADC0820CCMSA?
- A: The ADC0820CCMSA is an 8-bit analog-to-digital converter.
- Q: What is the sampling rate?
- A: The sampling rate is not specified in the provided technical data.
- Q: How many channels does it have?
- A: It has a single input channel.
- Q: What interface does it use?
- A: It uses a parallel interface for data output.
- Q: What architecture does it use?
- A: It uses a Sample-and-Hold ADC (S/H-ADC) architecture.
- Q: What package is it available in?
- A: It comes in a 20-SSOP (0.209", 5.30mm Width) package.
