Texas Instruments ADS8330IBRSAT
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $22.59 | $22.59 |
| 15+ | $21.88 | $328.20 |
| 25+ | $21.40 | $535.00 |
| 50+ | $20.21 | $1,010.50 |
| 100+ | $17.84 | $1,784.00 |
| N+ | $3.57 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 1M |
| Number of Inputs | 2 |
| Input Type | Differential, Single Ended |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 1.65V ~ 5.5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 16-VQFN Exposed Pad |
| Supplier Device Package | 16-QFN (4x4) |
| ROHS |  |
The ADS8330IBRSAT is a 16-bit, 2-channel analog-to-digital converter from Texas Instruments with a sampling rate of 1M SPS. It features an S/H-ADC architecture and SPI interface, providing efficient data transfer. Operating from -40°C to 85°C, this ADC is housed in a 16-VQFN Exposed Pad package. It is ideal for multi-channel data acquisition, industrial automation, and medical devices where high resolution and speed are required with an external reference.
