Texas Instruments ADS8361IDBQR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $17.82 | $17.82 |
| 15+ | $17.26 | $258.90 |
| 25+ | $16.88 | $422.00 |
| 50+ | $15.95 | $797.50 |
| 100+ | $14.07 | $1,407.00 |
| N+ | $2.81 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 500k |
| Number of Inputs | 4 |
| Input Type | Differential |
| Data Interface | SPI |
| Configuration | MUX-S/H-MUX-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 2 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 2.7V ~ 3.6V |
| Features | Simultaneous Sampling |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 24-SSOP (0.154", 3.90mm Width) |
| Supplier Device Package | 24-SSOP |
| ROHS |  |
The Texas Instruments ADS8361IDBQR is a 16-bit, 4-channel ADC with a maximum sampling rate of 500k SPS. It features a flexible MUX-S/H-MUX-ADC architecture and a simple SPI interface, making it easy to integrate into a variety of systems. Its wide operating temperature range and compact SSOP package make it suitable for industrial, automotive, and portable applications where space and reliability are key.
- Compact Size: The 24-SSOP package saves valuable board space in space-constrained designs.
- High Resolution: 16-bit accuracy ensures precise measurement of analog signals.
- Flexible Input MUX: The MUX-S/H-MUX-ADC architecture allows for both simultaneous and sequential sampling configurations.
- Robust Temperature Range: Operates reliably from -40°C to 125°C, suitable for harsh environments.
Motor Control Feedback
The 4-channel, 500k SPS ADC with SPI output is well-suited for reading resolver or encoder signals in servo motor control loops, providing high-speed position and current feedback.
Portable Instrumentation
The small SSOP package and low power consumption make it ideal for battery-powered data loggers and portable test equipment requiring 16-bit accuracy.
Industrial Process Control
With a -40°C to 125°C temperature range, it can reliably digitize 4-20mA loop signals and sensor outputs in harsh industrial automation environments.
Medical Patient Monitoring
The high resolution and SPI interface enable accurate digitization of biopotential signals like ECG and EEG in compact, multi-channel patient monitors.
Automotive Sensor Interfaces
Its wide temperature range and 16-bit precision make it suitable for digitizing pressure, temperature, and position sensors in automotive engine control units.
Multi-Channel Data Loggers
The MUX-S/H-MUX-ADC architecture allows flexible channel scanning, making it a good fit for multi-sensor environmental monitoring systems.
- Q: What is the ADS8361IDBQR?
- A: It is a 16-bit, 4-channel analog-to-digital converter (ADC) from Texas Instruments with a MUX-S/H-MUX-ADC architecture.
- Q: What is the resolution of this ADC?
- A: The resolution is 16 bits, offering high precision for measurement applications.
- Q: What is the maximum sampling rate?
- A: The ADS8361IDBQR supports a maximum sampling rate of 500k SPS.
- Q: How many channels does it have?
- A: It has 4 input channels, which can be configured for simultaneous or sequential sampling.
- Q: What interface does it use?
- A: It uses a standard SPI interface for communication with microcontrollers and DSPs.
- Q: What is the package type?
- A: It is available in a compact 24-SSOP (0.154", 3.90mm Width) package.
