Texas Instruments ADS8507IBDW
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $20.24 | $20.24 |
| 15+ | $19.60 | $294.00 |
| 25+ | $19.17 | $479.25 |
| 50+ | $18.11 | $905.50 |
| 100+ | $15.98 | $1,598.00 |
| N+ | $3.20 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Tube | |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 40k |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | SPI, Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 28-SOIC |
| ROHS |  |
The ADS8507IBDW from Texas Instruments is a 16-bit analog-to-digital converter (ADC) designed for a wide range of industrial and instrumentation applications. It features a single input channel with a sample-and-hold circuit and supports a sampling rate of 40k SPS. The device offers both SPI and parallel interfaces, providing design flexibility for various system architectures. It can use either an external or internal voltage reference. Housed in a 28-SOIC package, the ADS8507IBDW operates over an industrial temperature range, making it a reliable choice for demanding environments.
- Dual Interface Options: Supports both SPI and parallel interfaces, offering flexibility for different microcontroller or DSP connections.
- Good Speed and Resolution: 16-bit resolution at 40k SPS provides a solid balance for many industrial and test applications.
- Flexible Reference: Can operate with either an external or internal reference, allowing for optimization of accuracy and cost.
- Industrial Reliability: Operates over -40°C to 85°C, ensuring dependable performance in harsh environments.
Industrial Data Acquisition
The ADS8507IBDW's 16-bit resolution and 40k SPS sampling rate make it suitable for industrial data acquisition systems where accurate and timely conversion of analog signals is required.
Motor Control Systems
Its speed and precision allow for accurate monitoring of motor currents and voltages, enabling efficient and reliable motor control in automation equipment.
Test and Measurement Equipment
The parallel interface allows for high-speed data transfer to DSPs or FPGAs, making it ideal for benchtop instruments like spectrum analyzers and data loggers.
Medical Instrumentation
With its high accuracy, it can be used in medical devices such as patient monitors and diagnostic equipment where precise signal conversion is critical.
Audio Processing
The 16-bit resolution and 40k SPS rate are sufficient for professional audio applications, providing high-fidelity digitization of analog audio signals.
- Q: What is the ADS8507IBDW?
- A: It is a 16-bit analog-to-digital converter (ADC) from Texas Instruments with a sample-and-hold (S/H) architecture.
- Q: What is the resolution of the ADS8507IBDW?
- A: It provides 16-bit resolution, offering a good balance between accuracy and speed.
- Q: What is the sampling rate of the ADS8507IBDW?
- A: The ADS8507IBDW supports a sampling rate of 40k SPS (samples per second).
- Q: How many channels does it have?
- A: It features a single (1) input channel.
- Q: What interfaces does it support?
- A: It offers both SPI and Parallel interfaces, providing flexibility in system design.
- Q: What is the operating temperature range?
- A: It operates over an industrial temperature range of -40°C to 85°C and comes in a 28-SOIC package.
