Texas Instruments AMC1306M05DWV
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | Dhs. 30.94 | Dhs. 30.94 |
| 15+ | Dhs. 29.95 | Dhs. 449.25 |
| 25+ | Dhs. 29.30 | Dhs. 732.50 |
| 50+ | Dhs. 27.67 | Dhs. 1,383.50 |
| 100+ | Dhs. 24.41 | Dhs. 2,441.00 |
| N+ | Dhs. 4.88 | Price Inquiry |
Request Quote / Inquiry
Texas Instruments AMC1306M05DWV - 16-Bit Isolated Delta-Sigma Modulator
The AMC1306M05DWV from Texas Instruments is a precision isolated delta-sigma modulator designed for high-performance current and voltage sensing applications in industrial, automotive, and power management systems. This single-channel isolated module delivers exceptional accuracy with 16-bit resolution and a 78kSPS sampling rate, making it ideal for motor control, solar inverters, and power supply monitoring.
Key Features & Benefits
- High-Precision Isolation: Galvanic isolation protects sensitive circuitry while maintaining signal integrity
- 16-Bit Resolution: Delivers accurate measurements for demanding applications
- 78kSPS Sampling Rate: Fast response time for real-time monitoring and control
- Wide Supply Range: 2.7V to 5.5V operation supports diverse system architectures
- Extended Temperature Range: -40°C to 125°C for harsh industrial environments
- Compact 8-SOIC Package: Space-efficient surface mount design
- RoHS Compliant: Meets environmental standards for global markets
Applications
- Motor drive current sensing
- Solar inverter monitoring
- Power supply voltage and current measurement
- Industrial automation and control systems
- Automotive battery management systems
- Uninterruptible power supplies (UPS)
Why Choose This Component?
As an authorized distributor, we provide genuine Texas Instruments components with full traceability, comprehensive datasheets, and technical support. The AMC1306M05DWV offers engineers a reliable, high-performance solution for isolated sensing applications with proven long-term availability and compliance with international environmental standards.
Design Resources: Datasheets, reference designs, and application notes available to support your design-in process.
Related Products & Resources
- Explore more ADCs/DACs - Special Purpose components for your precision sensing applications
- Browse our complete catalog at HQICKEY for high-reliability semiconductor solutions
- Stay updated with industry insights and technical articles on our News & Technical Blog
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Tube | |
| Type | Isolated Module |
| Number of Channels | 1 |
| Resolution (Bits) | 16 b |
| Sampling Rate (Per Second) | 78k |
| Data Interface | CMOS, Serial |
| Voltage Supply Source | Analog and Digital |
| Voltage - Supply | 2.7V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 8-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 8-SOIC |
| ROHS |  |
No datasheet available. Please contact sales@hqickey.com for the latest datasheet.
