Microchip Technology ATTINY426-XFR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.84 | $0.84 |
| 15+ | $0.81 | $12.15 |
| 25+ | $0.79 | $19.75 |
| 50+ | $0.75 | $37.50 |
| 100+ | $0.66 | $66.00 |
| N+ | $0.13 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | tinyAVR® 2 |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Core Processor | AVR |
| Core Size | 8-Bit |
| Speed | 20MHz |
| Connectivity | I2C, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 18 |
| Program Memory Size | 4KB (4K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 128 x 8 |
| RAM Size | 512 x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 5.5V |
| Data Converters | A/D 15x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 20-SSOP |
| Package / Case | 20-SSOP (0.209", 5.30mm Width) |
| ROHS |  |
The Microchip ATTINY426-XFR is an 8-bit AVR microcontroller designed for extended temperature operation. It offers 4KB of Flash and 512 bytes of SRAM, running at up to 20MHz from a 1.8V to 5.5V supply. Housed in a 20-SSOP package, it integrates PWM, a watchdog timer, and brown-out detection, providing a compact and reliable solution for automotive and industrial control.
- Extended temperature range (-40°C to 125°C): Enables deployment in engine bays and industrial ovens where standard MCUs fail.
- 20MHz performance: Ensures responsive control loops even in time-critical applications like actuator regulation.
- 20-SSOP package: Offers a smaller footprint than DIP while remaining through-hole compatible for prototyping.
- Integrated analog peripherals: Reduces external component count by providing ADC and comparator on-chip.
Automotive Sensor Nodes
The 125°C junction temperature rating allows placement near engines or exhaust systems. The 20MHz AVR core can handle CAN or LIN message processing when paired with an external transceiver.
Industrial Actuator Control
With PWM outputs and a robust WDT, this MCU can drive solenoids or valves in factory automation, ensuring fail-safe operation in high-temperature zones.
HVAC Zone Controllers
The wide voltage range and 4KB Flash are perfect for implementing thermostat algorithms, while the SSOP package fits neatly on compact control boards.
Power Supply Monitoring
Its ADC can monitor output voltages and currents, while the brown-out detector ensures the MCU resets cleanly during power dips, protecting downstream equipment.
Portable Test Instruments
For handheld meters, the low-power sleep modes and 1.8V operation extend battery life, while the 20MHz speed allows fast measurement updates.
Lighting Ballasts
The PWM channels can generate high-frequency drive signals for LED or fluorescent ballasts, with the extended temperature range supporting enclosed fixtures.
- Q: What is the temperature range for the ATTINY426-XFR?
- A: It is rated for -40°C to 125°C, making it suitable for harsh automotive and industrial environments.
- Q: What is the maximum clock speed?
- A: The device operates at up to 20MHz with a supply voltage of 1.8V to 5.5V.
- Q: How much program memory is available?
- A: It has 4KB of Flash and 512 bytes of SRAM, sufficient for small control loops and state machines.
- Q: What package does it use?
- A: It comes in a 20-SSOP package with a 5.30mm width, offering a good balance between size and ease of soldering.
- Q: Does it support PWM and analog sensing?
- A: Yes, it includes PWM channels and a 12-bit ADC, along with a comparator for analog signal processing.
