Harris Corporation CD82C85
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $47.20 | $47.20 |
| 15+ | $10.86 | $162.90 |
| 25+ | $10.62 | $265.50 |
| 50+ | $10.03 | $501.50 |
| 100+ | $8.85 | $885.00 |
| N+ | $1.77 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Harris Corporation |
| Product Series | |
| Packaging | Bulk | |
| Type | Clock Generator |
| PLL | No |
| Input | TTL, Crystal |
| Output | CMOS, TTL |
| Number of Circuits | 1 |
| Ratio - Input:Output | 1:3 |
| Differential - Input:Output | No/No |
| Frequency - Max | 25MHz |
| Divider/Multiplier | Yes/No |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 24-DIP (0.300", 7.62mm) |
| Supplier Device Package | 24-CERDIP |
The CD82C85 is a straightforward clock generator from Harris Corporation, designed for microprocessor systems. Without a PLL, it generates clocks up to 25MHz from TTL or crystal inputs, providing CMOS and TTL outputs. With 1 circuit and a 24-DIP package, it is ideal for legacy and educational applications requiring simple, reliable timing.
- Simple Design: No PLL complexity, ideal for basic clock generation.
- Dual Output Logic: Provides both CMOS and TTL outputs for broad compatibility.
- Through-Hole Package: 24-DIP is easy to handle and solder.
- Cost-Effective: Suitable for budget-sensitive projects.
Microprocessor Clock Generation
Provide system clocks for 8085/8086-based embedded systems. The TTL/crystal input and CMOS/TTL outputs ensure compatibility with legacy processors.
Industrial Control Systems
Generate timing for PLCs and industrial computers. The 25MHz frequency is sufficient for control logic and peripheral interfaces.
Educational and Hobbyist Projects
Use in retro computing projects and breadboard designs. The DIP package is easy to prototype and solder.
Legacy System Maintenance
Replace obsolete clock generators in existing equipment. The 0°C to 70°C range suits indoor environments.
Simple Digital Timing
Create basic clock signals for logic circuits. The lack of PLL simplifies design for low-cost applications.
- Q: What type of device is the CD82C85?
- A: It is a Clock Generator from Harris Corporation, designed for microprocessor systems.
- Q: Does it have a PLL?
- A: No, it does not include a PLL; it generates clocks directly from a crystal or TTL input.
- Q: What input types are supported?
- A: It accepts TTL or Crystal inputs for clock generation.
- Q: What output types are available?
- A: It provides CMOS and TTL outputs, compatible with various logic families.
- Q: How many circuits does it have?
- A: It contains 1 circuit.
- Q: What is the maximum frequency and package?
- A: It supports up to 25MHz and comes in a 24-DIP package, operating from 0°C to 70°C.
