Bridgetek Pte Ltd. FT931Q-T
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $25.75 | $25.75 |
| 15+ | $5.92 | $88.80 |
| 25+ | $5.80 | $145.00 |
| 50+ | $5.47 | $273.50 |
| 100+ | $4.83 | $483.00 |
| N+ | $0.97 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Bridgetek Pte Ltd. |
| Product Series | FT93x |
| Packaging | Tray | NULL |
| Core Processor | FT32 |
| Core Size | 32-Bit Single-Core |
| Speed | 100MHz |
| Connectivity | I2C, SD, SPI, UART/USART, USB |
| Peripherals | POR, PWM, WDT |
| Number of I/O | 40 |
| Program Memory Size | 128KB (128K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 32K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.97V ~ 3.63V |
| Data Converters | A/D 3x10b; D/A 2x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 56-QFN (8x8) |
| Package / Case | 56-VFQFN Exposed Pad |
| ROHS |  |
The Bridgetek FT931Q-T is a 32-bit microcontroller based on the FT32 core, operating at up to 100MHz. It features 128KB of flash memory and 32KB of RAM, packaged in a 56-VFQFN with exposed pad. Running on 2.97V to 3.6V, it includes POR, PWM, and WDT peripherals. This MCU is designed for cost-sensitive embedded applications requiring moderate performance and compact size, with an operating temperature range of -40°C to 85°C.
- 100MHz FT32 core provides efficient processing for display and control tasks.
- 56-VFQFN package with exposed pad improves thermal performance in compact designs.
- Integrated PWM and WDT reduce external components for reliable operation.
- Low 3.3V operation minimizes power consumption in battery-powered devices.
Embedded Display Controllers
The FT32 core at 100MHz with 128KB flash can drive small TFT displays and handle touch input, making it suitable for smart appliances.
Portable Instrumentation
With low 3.3V operation and a compact 56-VFQFN package, it fits into handheld multimeters and environmental sensors.
IoT Edge Nodes
Its PWM and WDT enable reliable sensor reading and actuation for smart home devices, with the exposed pad aiding heat dissipation in sealed enclosures.
Motor Control for Drones
High-speed PWM outputs and 100MHz processing allow for precise ESC (Electronic Speed Controller) algorithms in small UAVs.
Point-of-Sale Terminals
The FT931Q-T can manage keypad scanning, display updates, and communication protocols in compact POS devices.
LED Lighting Systems
With multiple PWM channels, it can control RGB LED color mixing and dimming for architectural lighting.
- Q: What is the core processor in the FT931Q-T?
- A: It uses the FT32 core, running at up to 100MHz.
- Q: How much flash and RAM does it have?
- A: It has 128KB of flash memory and 32KB of RAM.
- Q: What is the supply voltage range?
- A: The operating voltage is 2.97V to 3.63V, ideal for 3.3V applications.
- Q: What package is available?
- A: It comes in a 56-VFQFN package with an exposed pad for thermal management.
- Q: Does it include a watchdog timer?
- A: Yes, it features a WDT along with POR and PWM.
