Analog Devices Inc. LT1959IR#PBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $15.11 | $15.11 |
| 15+ | $14.63 | $219.45 |
| 25+ | $14.31 | $357.75 |
| 50+ | $13.52 | $676.00 |
| 100+ | $11.93 | $1,193.00 |
| N+ | $2.39 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck, SEPIC |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4.3V |
| Voltage - Input (Max) | 15V |
| Voltage - Output (Min/Fixed) | 1.21V |
| Voltage - Output (Max) | 12.9V |
| Current - Output | 4.5A (Switch) |
| Frequency - Switching | 500kHz |
| Synchronous Rectifier | No |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA |
| Supplier Device Package | DDPAK-7 |
| ROHS |
The LT1959IR is a monolithic high-frequency switching regulator from Analog Devices, designed for Buck and SEPIC topologies. It operates from a 4.3V to 15V input, delivering up to 4.5A of switch current. With a fixed 500kHz switching frequency, it enables compact, low-profile designs using small inductors and capacitors. The device is available in a TO-263-8 (D2PAK) package, offering excellent thermal performance for demanding applications.
