Analog Devices Inc. LTC1403AIMSE#PBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $21.83 | $21.83 |
| 15+ | $21.14 | $317.10 |
| 25+ | $20.68 | $517.00 |
| 50+ | $19.53 | $976.50 |
| 100+ | $17.24 | $1,724.00 |
| N+ | $3.45 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 2.8M |
| Number of Inputs | 1 |
| Input Type | Differential, Single Ended |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 2.7V ~ 3.6V |
| Voltage - Supply, Digital | 2.7V ~ 3.6V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad |
| Supplier Device Package | 10-MSOP-EP |
| ROHS |  |
The LTC1403AIMSE#PBF is a high-speed 14-bit analog-to-digital converter from Analog Devices Inc. It offers a remarkable 2.8M SPS sampling rate, making it ideal for applications requiring fast and accurate signal conversion. With a single input channel and SPI interface, it integrates easily into digital systems. The device supports both external and internal references and operates from -40°C to 85°C. Housed in a compact 10-MSOP Exposed Pad package, it is perfect for space-constrained, high-performance designs.
- Ultra-Fast Sampling: 2.8M SPS enables high-bandwidth signal capture.
- Compact Size: 10-MSOP package saves board space in dense designs.
- Simple Digital Interface: SPI interface reduces pin count and simplifies PCB routing.
- Wide Temperature Range: -40°C to 85°C ensures operation in demanding environments.
- Flexible Reference: Internal or external reference options provide design flexibility.
High-Speed Single-Channel Data Acquisition
The 2.8M SPS sampling rate and SPI interface make it perfect for high-speed, single-channel data acquisition systems where fast and accurate conversion is required.
Portable Instrumentation
The small 10-MSOP package and low power consumption make it suitable for battery-powered portable test equipment.
Communication Systems
The high sampling rate supports digitization of IF signals in software-defined radios and other communication receivers.
Industrial Automation
With a wide temperature range (-40°C to 85°C), it can be used in industrial control loops requiring fast response times.
Medical Ultrasound
The high-speed conversion capability is ideal for ultrasound signal processing where high-frequency analog signals need to be digitized.
Optical Sensor Interfaces
The SPI interface simplifies connection to microcontrollers for optical sensing applications like LIDAR.
- Q: What type of ADC is the LTC1403AIMSE#PBF?
- A: It is a 14-bit successive approximation (S/H-ADC) analog-to-digital converter.
- Q: What is the resolution of the LTC1403AIMSE#PBF?
- A: The resolution is 14 bits.
- Q: What is the sampling rate of the LTC1403AIMSE#PBF?
- A: The sampling rate is 2.8M SPS (samples per second).
- Q: How many channels does the LTC1403AIMSE#PBF have?
- A: It has 1 input channel.
- Q: What interface does the LTC1403AIMSE#PBF use?
- A: It uses an SPI interface.
- Q: What is the package type of the LTC1403AIMSE#PBF?
- A: It comes in a 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad package.
