Analog Devices Inc. LTC2312ITS8-14#TRMPBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $19.90 | $19.90 |
| 15+ | $19.27 | $289.05 |
| 25+ | $18.86 | $471.50 |
| 50+ | $17.81 | $890.50 |
| 100+ | $15.71 | $1,571.00 |
| N+ | $3.14 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 500k |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | Internal |
| Voltage - Supply, Analog | 2.7V ~ 3.6V, 5V |
| Voltage - Supply, Digital | 2.7V ~ 3.6V, 5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | SOT-23-8 Thin, TSOT-23-8 |
| Supplier Device Package | TSOT-23-8 |
| ROHS |  |
The LTC2312ITS8-14 is a high-speed, 14-bit analog-to-digital converter from Analog Devices, designed for precision measurement applications. It features a single input channel and a maximum sampling rate of 500k SPS, ensuring rapid and accurate data conversion. The device utilizes a SAR architecture with an internal reference, simplifying external circuitry. Communication is handled via a standard SPI interface, making integration with microcontrollers straightforward. Housed in a compact SOT-23-8 Thin package, it is well-suited for space-constrained designs in industrial, automotive, and portable instrumentation.
- High-Speed Precision: 14-bit resolution at 500k SPS provides fast and accurate conversion for demanding real-time applications.
- Compact Footprint: The SOT-23-8 Thin package saves valuable PCB space, ideal for miniaturized devices.
- Simplified Design: The integrated internal reference reduces external component count and simplifies the overall system design.
- Easy Integration: The standard SPI interface ensures seamless communication with a wide range of microcontrollers and DSPs.
High-Speed Data Acquisition Systems
The 500k SPS sampling rate and 14-bit resolution make it ideal for portable data loggers and high-speed industrial data acquisition modules where accuracy and speed are balanced.
Precision Sensor Signal Digitization
With its internal reference and SPI interface, this ADC is perfect for digitizing outputs from temperature sensors, pressure transducers, and strain gauges in embedded control systems.
Battery-Powered Instrumentation
The TSOT-23-8 package and low power consumption of the SAR architecture enable compact, energy-efficient designs for handheld multimeters and field instruments.
Motor Control Feedback Loops
Its fast sampling and single-channel simplicity allow for precise current and voltage sensing in motor control applications, ensuring smooth and efficient operation.
Industrial Process Control
The -40°C to 85°C temperature range ensures reliable performance in factory automation and process control environments where environmental conditions vary.
- Q: What type of ADC is the LTC2312ITS8-14?
- A: It is a 14-bit successive approximation register (SAR) analog-to-digital converter with a sample-and-hold architecture.
- Q: What is the resolution of this ADC?
- A: The LTC2312ITS8-14 provides 14-bit resolution.
- Q: What is the maximum sampling rate?
- A: It supports a sampling rate of 500k SPS (samples per second).
- Q: How many input channels does it have?
- A: It features a single (1) input channel.
- Q: What digital interface does it use?
- A: It uses a standard SPI (Serial Peripheral Interface) for communication.
- Q: What is the package type?
- A: It is available in a SOT-23-8 Thin / TSOT-23-8 package.
