Analog Devices Inc. LTC2366HTS8#TRMPBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $18.96 | $18.96 |
| 15+ | $18.36 | $275.40 |
| 25+ | $17.96 | $449.00 |
| 50+ | $16.97 | $848.50 |
| 100+ | $14.97 | $1,497.00 |
| N+ | $2.99 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 3M |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 2.35V ~ 3.6V |
| Voltage - Supply, Digital | 2.35V ~ 3.6V |
| Features | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | SOT-23-8 Thin, TSOT-23-8 |
| Supplier Device Package | TSOT-23-8 |
| ROHS |  |
The LTC2366HTS8#TRMPBF from Linear Technology is a high-speed 12-bit analog-to-digital converter (ADC) with a sampling rate of 3M SPS. It features a single input channel and uses a successive approximation (S/H) architecture. The device communicates via an SPI interface and requires an external reference. Housed in a compact SOT-23-8 package, this ADC is designed for high-speed applications including data acquisition, communications, and automotive systems.
- Very High Speed: 3M SPS sampling rate enables capture of fast, dynamic signals.
- Extended Temperature Range: Operates from -40°C to 125°C, ideal for automotive and industrial environments.
- Ultra-Compact Package: SOT-23-8 package is one of the smallest available, saving significant board space.
- Low Power: Designed for power-sensitive applications, extending battery life in portable devices.
High-Speed Data Acquisition
The LTC2366HTS8's 3M SPS sampling rate makes it ideal for high-speed data acquisition systems, capturing fast transient signals with 12-bit accuracy.
Communications Systems
In wireless and wired communication systems, this ADC can digitize IF signals and baseband data, enabling high-throughput signal processing.
Portable Test Equipment
Its small TSOT-23 package and high speed make it perfect for portable oscilloscopes and logic analyzers where space and performance are critical.
Automotive Sensors
With an extended temperature range up to 125°C, this ADC is suitable for automotive sensor applications such as engine control and battery management.
Video Digitization
The high sampling rate allows for digitization of composite video signals, making it useful in video capture and processing applications.
- Q: What is the resolution of the LTC2366HTS8?
- A: The LTC2366HTS8 is a 12-bit analog-to-digital converter.
- Q: What is the sampling rate of this ADC?
- A: It features a high sampling rate of 3M SPS.
- Q: How many channels does the LTC2366HTS8 have?
- A: This device has 1 input channel.
- Q: What interface does the LTC2366HTS8 use?
- A: It uses an SPI serial interface.
- Q: What is the architecture of this ADC?
- A: It uses a S/H-ADC (sample and hold) architecture.
- Q: What is the package type for the LTC2366HTS8?
- A: It comes in a SOT-23-8 Thin, TSOT-23-8 package.
