Analog Devices Inc. LTC2368IMS-24#PBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $48.71 | $48.71 |
| 15+ | $47.17 | $707.55 |
| 25+ | $46.14 | $1,153.50 |
| 50+ | $43.58 | $2,179.00 |
| 100+ | $38.45 | $3,845.00 |
| N+ | $7.69 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Number of Bits | 24 |
| Sampling Rate (Per Second) | 1M |
| Number of Inputs | 1 |
| Input Type | Pseudo-Differential |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 2.375V ~ 2.625V |
| Voltage - Supply, Digital | 2.375V ~ 2.625V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 16-TFSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 16-MSOP |
| ROHS |  |
The LTC2368IMS-24#PBF is a high-performance 24-bit analog-to-digital converter (ADC) from Analog Devices, designed for precision measurement applications. It offers a fast sampling rate of 1 MSPS and a single input channel, ensuring accurate and rapid data conversion. The device utilizes a successive approximation register (SAR) architecture with a sample-and-hold circuit, providing excellent linearity and low noise. It communicates via a standard SPI interface, making it easy to integrate with a wide range of microcontrollers and digital signal processors. This ADC is well-suited for demanding applications such as high-precision data acquisition, industrial automation, and medical instrumentation.
- High Precision: 24-bit resolution provides exceptional accuracy for demanding measurement applications, minimizing quantization errors.
- Fast Sampling Rate: 1 MSPS throughput enables high-speed data acquisition, capturing fast-changing signals without missing critical information.
- Easy Integration: The standard SPI interface simplifies connection to microcontrollers, reducing design complexity and time-to-market.
- Compact and Reliable: Housed in a small 16-TFSOP package and rated for -40°C to +85°C, it is suitable for space-constrained and industrial environments.
High-Precision Sensor Digitization
The 24-bit resolution and 1 MSPS sampling rate make the LTC2368IMS-24#PBF ideal for digitizing outputs from high-precision sensors such as strain gauges, pressure transducers, and thermocouples, ensuring minimal signal loss and high accuracy.
Data Acquisition Systems (DAQ)
In multi-channel DAQ systems, this ADC's fast 1 MSPS throughput and SPI interface allow for efficient, high-speed data streaming to host processors, enabling real-time monitoring and analysis in industrial and laboratory settings.
Medical Instrumentation
For medical devices like patient monitoring systems and diagnostic equipment, the high resolution ensures accurate representation of biological signals, which is critical for reliable diagnostics and patient safety.
Industrial Automation and Control
In industrial process control, the LTC2368's precision and speed facilitate accurate monitoring of analog signals from transducers, enabling precise control loops and improving overall system efficiency and product quality.
Portable Instrumentation
The low power consumption and small 16-TFSOP package make it suitable for battery-powered portable instruments, where space and power efficiency are crucial without compromising on measurement accuracy.
- Q: What type of ADC is the LTC2368IMS-24#PBF?
- A: It is a 24-bit successive approximation register (SAR) analog-to-digital converter with a sample-and-hold (S/H) architecture.
- Q: What is the resolution of this ADC?
- A: The LTC2368IMS-24#PBF provides 24-bit resolution, offering high precision for demanding measurement applications.
- Q: What is the maximum sampling rate?
- A: It supports a sampling rate of 1 MSPS (1 million samples per second).
- Q: How many input channels does it have?
- A: This device features a single input channel.
- Q: What digital interface does it use?
- A: It uses a serial peripheral interface (SPI) for communication with microcontrollers or DSPs.
- Q: What is the operating temperature range?
- A: It operates over an industrial temperature range of -40°C to +85°C and comes in a 16-pin TFSOP package.
