Analog Devices Inc. LTC2512CDKD-24#PBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $23.06 | $23.06 |
| 15+ | $22.33 | $334.95 |
| 25+ | $21.84 | $546.00 |
| 50+ | $20.63 | $1,031.50 |
| 100+ | $18.20 | $1,820.00 |
| N+ | $3.64 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Number of Bits | 24 |
| Sampling Rate (Per Second) | 1.6M |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 2.375V ~ 2.625V |
| Voltage - Supply, Digital | 2.375V ~ 2.625V |
| Features | - |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 24-WFDFN Exposed Pad |
| Supplier Device Package | 24-DFN (7x4) |
| ROHS |  |
The LTC2512CDKD-24#PBF is a high-speed, 24-bit analog-to-digital converter from Analog Devices Inc. It achieves an impressive 1.6M SPS sampling rate with a single input channel, using an S/H-ADC architecture. The device communicates via an SPI interface and is housed in a compact 24-WFDFN package. It is designed for demanding applications such as vibration analysis, medical imaging, and high-end instrumentation where speed and precision are paramount.
- Exceptional Resolution: 24-bit output provides extremely fine granularity, ideal for measuring very small signal variations.
- High-Speed Sampling: The 1.6M SPS rate allows for accurate capture of fast-changing signals without aliasing.
- Compact Package: The 24-WFDFN Exposed Pad package saves valuable PCB space in dense designs.
- Simple Digital Interface: The SPI interface ensures easy integration with a wide range of microcontrollers and FPGAs.
High-Speed Vibration Analysis
The 24-bit resolution and 1.6M SPS sampling rate enable precise digitization of high-frequency vibration signals for predictive maintenance.
Seismic and Geophysical Instruments
Its high resolution and speed are ideal for capturing wide dynamic range signals in seismic data acquisition systems.
Precision Audio Test Equipment
The combination of high resolution and sampling rate makes it suitable for professional audio analysis and measurement.
Medical Ultrasound Systems
Capable of digitizing high-frequency ultrasound echoes with excellent detail, improving image quality in diagnostic devices.
High-Performance Data Acquisition Cards
Its speed and precision make it a key component in PCIe or USB-based DAQ cards for laboratory and industrial testing.
- Q: What is the resolution of the LTC2512CDKD-24#PBF?
- A: This ADC offers a high resolution of 24 bits.
- Q: What is the sampling rate?
- A: It supports a fast sampling rate of 1.6M SPS.
- Q: How many input channels does it have?
- A: It is a single-channel (1 input) ADC.
- Q: What digital interface is used?
- A: It communicates via an SPI (Serial Peripheral Interface).
- Q: What is the architecture of this converter?
- A: It uses an S/H-ADC architecture with a sample-and-hold circuit.
- Q: What is the package type?
- A: It comes in a 24-WFDFN Exposed Pad package.
