Analog Devices Inc./Maxim Integrated MAX194ACWE+
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $144.10 | $144.10 |
| 15+ | $33.15 | $497.25 |
| 25+ | $32.43 | $810.75 |
| 50+ | $30.63 | $1,531.50 |
| 100+ | $27.02 | $2,702.00 |
| N+ | $5.40 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Marketplace | Tube |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 85k |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | ±5V |
| Voltage - Supply, Digital | ±5V |
| Features | - |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| ROHS |  |
The MAX194ACWE+ from Analog Devices is a precision 14-bit analog-to-digital converter with a maximum sampling rate of 85 kSPS. It features a simple SPI interface, making it easy to connect to a wide variety of microcontrollers and digital systems. The S/H-ADC architecture ensures accurate conversion of slowly varying signals. Housed in a standard 16-SOIC package, this ADC is an excellent choice for industrial process control, precision measurement, and portable instrumentation where accuracy and ease of use are paramount.
- High Accuracy: 14-bit resolution delivers precise digital representation of analog signals.
- Simple Integration: The SPI interface requires only a few pins, simplifying PCB design and firmware development.
- Low Power Consumption: Ideal for battery-powered and portable devices.
- Standard Package: The 16-SOIC package is widely available and easy to solder, facilitating manufacturing.
Industrial Process Control
The 14-bit resolution and SPI interface make it ideal for precise monitoring of industrial sensors like temperature, pressure, and flow in PLCs.
Precision Weigh Scales
Its high resolution ensures accurate weight measurements in laboratory and industrial scales, even with small load variations.
Battery Monitoring Systems
For monitoring voltage and current in battery packs, this ADC provides the necessary accuracy for state-of-charge estimation.
Data Logging Systems
The SPI interface simplifies connection to data loggers, enabling long-term, high-accuracy recording of environmental or industrial data.
Medical Instrumentation
In devices like patient monitors, the MAX194ACWE+ can accurately digitize signals from biological sensors.
Portable Test Equipment
Its low speed and low power consumption make it suitable for battery-powered multimeters and other portable instruments.
- Q: What is the resolution of the MAX194ACWE+?
- A: This ADC offers 14-bit resolution, providing high accuracy for precision measurement applications.
- Q: What is the sampling rate of this ADC?
- A: It has a maximum sampling rate of 85 kSPS (85k SPS), suitable for low-to-medium speed applications.
- Q: How many channels does this ADC have?
- A: It features a single input channel (1 channel).
- Q: What interface does this ADC use?
- A: It uses a standard SPI interface, which is easy to integrate with most microcontrollers.
- Q: What is the architecture of this ADC?
- A: It uses a Sample-and-Hold (S/H-ADC) architecture for accurate signal conversion.
- Q: What is the package type?
- A: It comes in a 16-SOIC package, which is widely used and easy to handle in manufacturing.
