onsemi MC7906CTG
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.40 | $1.40 |
| 15+ | $1.35 | $20.25 |
| 25+ | $1.32 | $33.00 |
| 50+ | $1.25 | $62.50 |
| 100+ | $1.10 | $110.00 |
| N+ | $0.22 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | onsemi |
| Product Series | |
| Packaging | Tube | |
| Output Configuration | Negative |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | -35V |
| Voltage - Output (Min/Fixed) | -6V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 1.3V @ 1A (Typ) |
| Current - Output | 1A |
| Current - Quiescent (Iq) | - |
| Current - Supply (Max) | - |
| PSRR | 65dB (120Hz) |
| Control Features | - |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | 0°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | TO-220 |
| ROHS |  |
The onsemi MC7906CTG is a fixed -6V negative linear regulator delivering 1A. With 1.3V typical dropout and 65dB PSRR at 120Hz, it provides stable negative rails for analog and industrial applications. The TO-220 package ensures excellent thermal performance for continuous operation.
- Negative Rail Solution: Dedicated -6V output simplifies dual-supply designs.
- High Ripple Rejection: 65dB at 120Hz filters mains hum effectively.
- Thermal Robustness: TO-220 package dissipates heat efficiently at 1A.
- Proven Reliability: onsemi's legacy MC79xx series is industry-standard.
Dual-Supply Op-Amp Circuits
Provides a clean -6V rail for precision operational amplifiers in audio and instrumentation, with 65dB ripple rejection at 120Hz.
Industrial Control Systems
TO-220 package with metal tab allows easy heatsinking for continuous 1A loads in PLC and motor control boards.
Audio Equipment
Negative rail for audio codecs and preamplifiers, ensuring symmetric supply for low distortion.
Telecom Line Cards
Stable -6V for line drivers and receivers in legacy telephony systems.
Test & Measurement
Reliable negative supply for DAC/ADC reference circuits in benchtop instruments.
Automotive Sensor Interfaces
onsemi's robust TO-220 package withstands vibration and thermal cycling in engine control units.
- Q: What is the output voltage?
- A: Fixed -6V negative output.
- Q: What is the maximum current?
- A: 1A output current.
- Q: What is the input voltage range?
- A: Input voltage is -6V (typical, negative rail).
- Q: What is the dropout voltage?
- A: 1.3V typical at 1A load.
- Q: What is the PSRR?
- A: 65dB at 120Hz.
- Q: What package is available?
- A: TO-220 package.
