Monolithic Power Systems Inc. MDC97476GJ-Z
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.43 | $1.43 |
| 15+ | $1.38 | $20.70 |
| 25+ | $1.35 | $33.75 |
| 50+ | $1.28 | $64.00 |
| 100+ | $1.13 | $113.00 |
| N+ | $0.23 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Monolithic Power Systems Inc. |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 1M |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | Serial |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | Supply |
| Voltage - Supply, Analog | 3V ~ 3.6V |
| Voltage - Supply, Digital | 3V ~ 3.6V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Supplier Device Package | TSOT-23-6 |
| ROHS |  |
The MDC97476GJ-Z is a 12-bit, 1 MSPS single-channel ADC from Monolithic Power Systems. It features a serial interface and uses a sample-and-hold architecture. The device operates from -40°C to 85°C and uses the supply as its reference, simplifying circuit design. The ultra-compact SOT-23-6 package is ideal for space-constrained applications such as portable devices and industrial sensors.
- Ultra-Compact: SOT-23-6 package fits in the smallest designs.
- Fast Sampling: 1 MSPS enables real-time signal processing.
- Simplified Design: Supply reference eliminates external reference components.
- Low Power: Suitable for battery-operated equipment.
Compact Sensor Readout
The small SOT-23 package and 1 MSPS rate make it perfect for space-limited sensor modules in consumer electronics.
Battery-Powered Devices
Low power consumption and supply reference simplify design in portable instruments like multimeters and thermometers.
Motor Control Feedback
12-bit resolution at 1 MSPS is sufficient for current sensing in brushless DC motor controllers.
Audio Level Detection
Fast sampling enables real-time audio level monitoring for automatic gain control in recording devices.
Industrial Alarm Systems
Reliable operation from -40°C to 85°C suits industrial alarm and monitoring circuits.
- Q: What is the resolution of the MDC97476GJ-Z?
- A: It is a 12-bit ADC.
- Q: What is the sampling rate?
- A: It supports a sampling rate of 1 MSPS.
- Q: How many channels does it have?
- A: It has a single input channel.
- Q: What interface does it use?
- A: It uses a serial interface.
- Q: What is the architecture?
- A: It uses a sample-and-hold (S/H) ADC architecture.
- Q: What is the package type?
- A: It comes in a SOT-23-6 Thin / TSOT-23-6 package.
