Monolithic Power Systems Inc. MP163AGSE-5-Z
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.55 | $0.55 |
| 15+ | $0.53 | $7.95 |
| 25+ | $0.52 | $13.00 |
| 50+ | $0.49 | $24.50 |
| 100+ | $0.44 | $44.00 |
| N+ | $0.09 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Monolithic Power Systems Inc. |
| Product Series | MP |
| Packaging | Tape & Reel (TR) | |
| Output Isolation | Non-Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Boost, Buck, Buck-Boost, Flyback |
| Voltage - Start Up | - |
| Voltage - Supply (Vcc/Vdd) | 5.3V ~ 6.5V |
| Duty Cycle | - |
| Frequency - Switching | - |
| Power (Watts) | - |
| Fault Protection | Current Limiting, Open Loop, Over Load, Over Temperature, Short Circuit, UVLO |
| Control Features | EN, Frequency Control, Soft Start |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| ROHS |  |
The Monolithic Power Systems MP163AGSE-5-Z is a non-isolated offline regulator with an integrated 700V switch. It supports Boost, Buck, Buck-Boost, and Flyback topologies with a 5.3V to 6.5V Vcc supply. Protection includes current limiting, open loop, over-load, over-temperature, short-circuit, and UVLO, while enable, frequency control, and soft start add design flexibility. It is offered in a 16-SOIC package rated for -40°C to +125°C junctions.
- Integrated 700V switch reduces external component count for offline designs.
- Comprehensive protection: current limiting, open loop, over-load, over-temperature, short-circuit, and UVLO.
- Enable, frequency control, and soft start for flexible control.
- Multi-topology support (Boost, Buck, Buck-Boost, Flyback).
- 16-SOIC package with -40°C to +125°C junction range.
Non-Isolated Offline Supplies
The 700V integrated switch supports direct offline Buck and Buck-Boost conversion for low-voltage control rails without isolation.
Appliance Control Electronics
Over-temperature, open-loop, and UVLO protection plus soft start support reliable auxiliary supplies in appliances.
Industrial Auxiliary Power
A -40°C to +125°C junction range and 16-SOIC package fit compact industrial control boards.
Low-Power Flyback Designs
Where a Flyback topology is used, the 700V switch and frequency control enable compact low-power conversion stages.
- Q: What topologies does the MP163AGSE-5-Z support?
- A: Boost, Buck, Buck-Boost, and Flyback in a non-isolated configuration.
- Q: What is the internal switch breakdown voltage?
- A: 700V.
- Q: What is the Vcc supply range?
- A: 5.3V to 6.5V.
- Q: What protections are included?
- A: Current limiting, open loop, over-load, over-temperature, short-circuit, and UVLO.
- Q: What package is it offered in?
- A: 16-SOIC (0.154", 3.90mm width).
