Monolithic Power Systems Inc. MP163BGSE-5-Z
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.63 | $0.63 |
| 15+ | $0.61 | $9.15 |
| 25+ | $0.59 | $14.75 |
| 50+ | $0.56 | $28.00 |
| 100+ | $0.50 | $50.00 |
| N+ | $0.10 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Monolithic Power Systems Inc. |
| Product Series | MP |
| Packaging | Tape & Reel (TR) | |
| Output Isolation | Non-Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Boost, Buck, Buck-Boost, Flyback |
| Voltage - Start Up | - |
| Voltage - Supply (Vcc/Vdd) | 5.3V ~ 6.5V |
| Duty Cycle | - |
| Frequency - Switching | - |
| Power (Watts) | - |
| Fault Protection | Current Limiting, Open Loop, Over Load, Over Temperature, Short Circuit, UVLO |
| Control Features | EN, Frequency Control, Soft Start |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| ROHS |  |
The MP163BGSE-5-Z from Monolithic Power Systems is a non-isolated offline regulator featuring an integrated 700V switch. It supports Boost, Buck, Buck-Boost, and Flyback topologies and operates from a 5.3V to 6.5V Vcc supply. The 16-SOIC package includes enable, frequency control, and soft start, with current limiting, open loop, over load, over temperature, short circuit, and UVLO protection across a -40°C to 125°C junction temperature range.
- Integrated 700V switch simplifies offline designs and reduces external parts.
- Four topology options (Boost, Buck, Buck-Boost, Flyback) support diverse output requirements.
- Comprehensive protection suite including current limiting, open loop, over load, over temperature, short circuit, and UVLO.
- Frequency control and soft start enable predictable startup and switching behavior.
- 16-SOIC package offers a familiar footprint for compact assemblies.
Offline Bias Supplies
The integrated 700V switch and 16-SOIC package make this device suitable for auxiliary bias rails derived from a rectified AC line. Frequency control and soft start help manage startup behavior in compact layouts.
Non-Isolated Buck Regulation
In Buck topology, the device provides direct-coupled step-down regulation. Current limiting and short circuit protection safeguard the load, while UVLO ensures the IC only operates once the supply is stable.
Buck-Boost and Boost Rails
For outputs that must sit above or below the input, Buck-Boost and Boost topologies offer design flexibility. The 5.3V to 6.5V Vcc supply supports reliable operation across the input range.
Flyback Configurations
The Flyback topology option supports transformer-coupled designs. Over temperature and open loop protection add robustness in thermally demanding enclosures.
- Q: What topologies does the MP163BGSE-5-Z support?
- A: It supports Boost, Buck, Buck-Boost, and Flyback topologies in a non-isolated configuration.
- Q: What is the breakdown voltage?
- A: The integrated switch is rated to 700V breakdown.
- Q: What is the Vcc supply range?
- A: The Vcc supply operates from 5.3V to 6.5V.
- Q: What protections are included?
- A: Current limiting, open loop, over load, over temperature, short circuit, and UVLO protection.
- Q: What package is used?
- A: A 16-SOIC package (0.154", 3.90mm width).
