Texas Instruments MSP430F5636IZQWR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | Dhs. 355,874.90 | Dhs. 355,874.90 |
| 15+ | Dhs. 344,636.75 | Dhs. 5,169,551.25 |
| 25+ | Dhs. 337,144.64 | Dhs. 8,428,616.00 |
| 50+ | Dhs. 318,414.39 | Dhs. 15,920,719.50 |
| 100+ | Dhs. 280,953.87 | Dhs. 28,095,387.00 |
| N+ | Dhs. 56,190.77 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | MSP430F5xx |
| Packaging | | Tape & Reel (TR) |
| Core Processor | MSP430 CPUXV2 |
| Core Size | 16-Bit |
| Speed | 20MHz |
| Connectivity | I2C, IrDA, LINbus, SCI, SPI, UART/USART, USB |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Number of I/O | 74 |
| Program Memory Size | 128KB (128K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 18K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Data Converters | A/D 16x12b; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 113-BGA Microstar Junior (7x7) |
| Package / Case | 113-VFBGA |
| ROHS |  |
Product Overview
The MSP430F5636IZQWR from Texas Instruments represents a pinnacle of 16-bit microcontroller design, featuring the advanced MSP430 CPUXV2 core architecture. Engineered for demanding embedded and industrial applications, this MCU combines exceptional processing power with ultra-low power consumption, making it the ideal choice for battery-powered and energy-efficient systems.
With 128KB of Flash program memory and 18KB of RAM, the MSP430F5636IZQWR delivers substantial resources for complex firmware development, real-time operating systems, and sophisticated control algorithms. The 20MHz clock speed ensures rapid instruction execution while maintaining the MSP430 family's legendary power efficiency.
Key Features & Technical Benefits
- High-Performance 16-Bit Architecture: MSP430 CPUXV2 core delivers efficient code execution with enhanced instruction set and improved interrupt handling for responsive real-time applications
- Generous Memory Resources: 128KB Flash memory provides ample space for application code, bootloaders, and data logging; 18KB RAM supports complex data structures and buffering requirements
- Comprehensive Connectivity Suite: Built-in I2C, IrDA, LINbus, SCI, SPI, UART/USART, and USB 2.0 interfaces enable seamless integration with sensors, displays, wireless modules, and host systems
- Rich Peripheral Integration: Brown-out Detect/Reset ensures system reliability, DMA controller offloads CPU for efficient data transfers, advanced PWM modules for motor control and LED dimming, Watchdog Timer for fail-safe operation
- Extensive I/O Capability: 74 general-purpose I/O pins with interrupt capability provide maximum design flexibility for sensor arrays, user interfaces, and control systems
- Precision Mixed-Signal Processing: 16 channels of 12-bit ADC deliver accurate analog measurements for sensor conditioning; 2 channels of 12-bit DAC enable precise analog output generation
- Wide Operating Voltage Range: 1.8V to 3.6V supply voltage supports direct battery operation, multi-voltage system designs, and low-power optimization strategies
- Industrial Temperature Range: -40°C to 85°C ambient temperature rating ensures reliable operation in harsh industrial, automotive, and outdoor environments
- Space-Efficient Package: 113-pin VFBGA (7x7mm Microstar Junior) surface mount package maximizes I/O density while minimizing PCB footprint for compact designs
- Internal Oscillator: Reduces external component count and BOM cost while simplifying board layout and improving system reliability
- RoHS Compliant: Lead-free, environmentally friendly manufacturing meets global regulatory standards and corporate sustainability requirements
