Analog Devices Inc./Maxim Integrated MX574ALEPI+
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $241.20 | $241.20 |
| 15+ | $134.99 | $2,024.85 |
| 25+ | $132.06 | $3,301.50 |
| 50+ | $124.72 | $6,236.00 |
| 100+ | $110.05 | $11,005.00 |
| N+ | $22.01 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 40k |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | Internal |
| Voltage - Supply, Analog | -11.4V ~ -15.75V, 4.75V ~ 5.25V |
| Voltage - Supply, Digital | -11.4V ~ -15.75V, 4.75V ~ 5.25V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Grade | - |
| Qualification | - |
| Package / Case | 28-DIP (0.600", 15.24mm) |
| Supplier Device Package | 28-PDIP |
The MX574ALEPI is a 12-bit, 40 kSPS analog-to-digital converter from Analog Devices/Maxim Integrated. It features a single input channel and a parallel interface, housed in a robust 28-DIP package. This ADC is designed for industrial control, data logging, and automotive applications, offering a simple and reliable solution for analog-to-digital conversion.
- Proven Reliability: Based on a well-established ADC architecture, ensuring dependable operation.
- Easy Integration: Parallel interface and DIP package simplify design and prototyping.
- Wide Temperature Range: Operates from -40°C to +85°C, suitable for harsh environments.
- Internal Reference: Includes an internal reference, reducing external component count.
Industrial Control Systems
The MX574ALEPI's 12-bit resolution and 40 kSPS sampling rate are suitable for industrial control systems, providing reliable digitization of sensor signals for process monitoring.
Data Logging
In data logging applications, this ADC can accurately capture analog signals over time, making it useful for environmental monitoring and test equipment.
Automotive Electronics
With its wide temperature range, this ADC is suitable for automotive sensor interfaces, such as those for temperature and pressure monitoring.
Legacy System Replacement
The DIP package and parallel interface make it a drop-in replacement for older 12-bit ADC designs, simplifying upgrades.
Educational Kits
Its through-hole package makes it ideal for educational and prototyping purposes, allowing easy breadboarding and experimentation.
- Q: What is the MX574ALEPI?
- A: It is a 12-bit, 40 kSPS analog-to-digital converter from Analog Devices/Maxim Integrated.
- Q: What is the resolution?
- A: The resolution is 12 bits.
- Q: What is the sampling rate?
- A: The sampling rate is 40 kSPS.
- Q: How many channels does it have?
- A: It has 1 input channel.
- Q: What interface does it use?
- A: It uses a Parallel interface.
- Q: What is the package type?
- A: It comes in a 28-DIP (0.600", 15.24mm) package.
MX574ALEPI.pdf
