Microchip Technology PIC16LF1718-E/SP
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | PIC® XLP™ 16F |
| Packaging | | Tube |
| Core Processor | PIC |
| Core Size | 8-Bit |
| Speed | 32MHz |
| Connectivity | I2C, LINbus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 24 |
| Program Memory Size | 28KB (16K x 14) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Data Converters | A/D 17x10b; D/A 1x5b, 1x8b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Supplier Device Package | 28-SPDIP |
| Package / Case | 28-DIP (0.300", 7.62mm) |
| ROHS |  |
The Microchip PIC16LF1718-E/SP is a low-power 8-bit MCU featuring a 28KB flash and 2KB RAM. It operates from 1.8V to 3.6V and runs at 32MHz. This DIP package device includes analog peripherals like op-amps and a 10-bit ADC, making it suitable for sensor and control applications.
- Ultra-low voltage operation (1.8V) – enables direct battery power without boost converters.
- High-temperature tolerance (125°C) – suitable for automotive and industrial environments.
- Integrated analog peripherals – reduces external component count and board space.
- Through-hole DIP package – easy for prototyping and manual assembly.
Battery-Powered Sensor Nodes
With a 1.8V minimum supply and low-power sleep modes, this MCU extends battery life in IoT and industrial sensors.
Portable Medical Devices
The integrated op-amps and 10-bit ADC enable precise signal conditioning for glucose meters and pulse oximeters.
Motor Control for Small Appliances
PWM modules and 32MHz speed allow efficient control of brushless DC motors in fans and pumps.
Automotive Interior Lighting
Operating up to 125°C, it handles LED dimming and color control in cabin lighting systems.
Industrial Process Control
Brown-out reset and watchdog timer ensure reliable operation in noisy factory environments.
Smart Home Thermostats
Low power and analog peripherals support temperature sensing and HVAC actuator control.
- Q: What is the operating voltage range of the PIC16LF1718-E/SP?
- A: It operates from 1.8V to 3.6V, ideal for low-power battery applications.
- Q: What package is this MCU available in?
- A: It comes in a 28-pin DIP (0.300", 7.62mm) package, suitable for through-hole prototyping.
- Q: What is the maximum CPU speed?
- A: The PIC16LF1718 runs at up to 32MHz, providing fast processing for its class.
- Q: Does it include analog features?
- A: Yes, it integrates a high-resolution ADC, op-amps, and comparators for mixed-signal designs.
