Texas Instruments SN74ALVC16244ADL
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $6.96 | $6.96 |
| 15+ | $1.60 | $24.00 |
| 25+ | $1.57 | $39.25 |
| 50+ | $1.48 | $74.00 |
| 100+ | $1.31 | $131.00 |
| N+ | $0.26 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | 74ALVC |
| Packaging | Marketplace | Tube |
| Part Status | Active |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 4 |
| Number of Bits per Element | 4 |
| Input Type | - |
| Output Type | 3-State |
| Current - Output High, Low | 24mA, 24mA |
| Voltage - Supply | 1.65V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 48-BSSOP (0.295", 7.50mm Width) |
| Supplier Device Package | 48-SSOP |
| ROHS |  |
The SN74ALVC16244ADL is a quad non-inverting buffer from Texas Instruments, part of the 74ALVC logic family. It features four channels with 3-State outputs, ideal for low-voltage bus applications. Operating from 1.65V to 3.6V, it supports 1.8V, 2.5V, and 3.3V logic levels. With 24mA source/sink capability, it drives moderate loads effectively. The 48-pin BSSOP package is suitable for high-density PCBs. This buffer is commonly used in memory interfacing, FPGA connections, and portable electronics.
- Wide 1.65V-3.6V Supply: Compatible with multiple low-voltage logic standards.
- Quad Channel Design: Buffers four independent signals in one package.
- 24mA Drive: Provides sufficient current for most low-voltage loads.
- 3-State Outputs: Enables bus sharing and power saving.
Low-Voltage Bus Buffering
Buffer address/data lines in 3.3V or 2.5V microcontrollers, ensuring signal integrity with 24mA drive capability.
Level Shifting (1.8V to 3.3V)
Interface low-voltage sensors or memory to a 3.3V logic system. The wide voltage range allows operation at both levels.
Memory Module Driving
Drive DDR or SDRAM address lines in low-voltage systems, providing the necessary fan-out and drive strength.
FPGA/CPLD Interface
Buffer signals between an FPGA and external peripherals, reducing loading on the FPGA's I/O pins.
Portable Electronics
In battery-powered devices, this buffer operates at low voltages, reducing power consumption while maintaining performance.
Telecom Line Cards
Use it in networking equipment to buffer control signals between ASICs and line interfaces at 3.3V.
- Q: What is the logic family of the SN74ALVC16244ADL?
- A: It belongs to the 74ALVC family, offering low-voltage, high-speed operation.
- Q: What is the function of this IC?
- A: It is a quad (4-channel) non-inverting buffer with 3-State outputs.
- Q: What is the voltage range?
- A: It operates from 1.65V to 3.6V, supporting 1.8V, 2.5V, and 3.3V systems.
- Q: What is the output current?
- A: It can source and sink 24mA.
- Q: What package is available?
- A: It comes in a 48-pin BSSOP (0.295", 7.50mm width) package.
- Q: What is the temperature range?
- A: It operates from -40°C to 85°C.
