Texas Instruments SN74LVC07ADT
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.87 | $0.87 |
| 15+ | $0.85 | $12.75 |
| 25+ | $0.83 | $20.75 |
| 50+ | $0.78 | $39.00 |
| 100+ | $0.69 | $69.00 |
| N+ | $0.14 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | 74LVC |
| Packaging | Marketplace | Cut Tape (CT) |
| Part Status | Active |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 6 |
| Number of Bits per Element | 1 |
| Input Type | - |
| Output Type | Open Drain |
| Current - Output High, Low | -, 24mA |
| Voltage - Supply | 1.65V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 14-SOIC |
| ROHS |  |
The SN74LVC07ADT is a 6-channel non-inverting buffer from Texas Instruments' 74LVC family. It operates over a wide supply voltage range of 1.65V to 5.5V, making it versatile for both 3.3V and 5V applications. With open-drain outputs capable of sinking 24mA, it is ideal for level shifting, bus buffering, and driving LEDs or relays. The device is available in a compact 14-pin SOIC package and supports a temperature range of -40°C to 125°C, suitable for industrial and automotive environments.
- Wide 1.65V to 5.5V Supply Range: Compatible with both 3.3V and 5V systems, simplifying mixed-voltage design.
- Open-Drain Outputs: Enable wired-OR logic and level shifting without external components.
- High Sink Current (24mA): Directly drives LEDs and low-impedance loads, reducing BOM cost.
- Extended Temperature Range (-40°C to 125°C): Reliable operation in harsh industrial and automotive environments.
- 6 Channels in SOIC-14 Package: Compact footprint saves board space while providing multiple buffered lines.
Level Shifting for Mixed-Voltage Systems
With open-drain outputs and a wide 1.65V to 5.5V supply range, the SN74LVC07ADT can translate signals between 3.3V and 5V logic, simplifying mixed-voltage interfacing.
Bus Buffering for High-Speed Data Lines
As a 6-channel non-inverting buffer, it can strengthen weak signals on I2C or SPI buses, ensuring reliable communication over longer traces.
Driving LEDs and Relays
The 24mA sink capability allows direct driving of LEDs or small relays without additional transistors, reducing component count.
Wired-OR Logic Implementation
Open-drain outputs enable wired-OR connections, ideal for interrupt lines or shared bus architectures where multiple devices need to assert a common signal.
Industrial Control Signal Conditioning
Operating from -40°C to 125°C, this buffer is suitable for industrial environments, buffering sensor outputs or control signals in PLCs and motor drives.
Automotive ECU Signal Isolation
In automotive ECUs, the SN74LVC07ADT can buffer and level-shift signals between different voltage domains, ensuring robust operation in harsh conditions.
- Q: What is the logic family of the SN74LVC07ADT?
- A: It belongs to the 74LVC family, known for low-voltage operation and high-speed performance.
- Q: What is the function of this IC?
- A: It is a non-inverting buffer with 6 channels, ideal for signal buffering and line driving.
- Q: What type of output does it have?
- A: It features open-drain outputs, allowing for wired-OR connections and level shifting.
- Q: What is the operating voltage range?
- A: It operates from 1.65V to 5.5V, making it compatible with both 3.3V and 5V systems.
- Q: What package is available?
- A: It comes in a 14-pin SOIC package (0.154", 3.90mm width).
- Q: What is the maximum sink current?
- A: Each output can sink up to 24mA, suitable for driving LEDs or low-impedance loads.
