Texas Instruments SN74LVC2G17QDCKRQ1
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.47 | $0.47 |
| 15+ | $0.45 | $6.75 |
| 25+ | $0.44 | $11.00 |
| 50+ | $0.42 | $21.00 |
| 100+ | $0.37 | $37.00 |
| N+ | $0.07 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | 74LVC |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Part Status | Active |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 2 |
| Number of Bits per Element | 1 |
| Input Type | Schmitt Trigger |
| Output Type | Push-Pull |
| Current - Output High, Low | 32mA, 32mA |
| Voltage - Supply | 1.65V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | SC-70-6 |
| ROHS |  |
The SN74LVC2G17QDCKRQ1 is a dual non-inverting buffer from Texas Instruments, part of the 74LVC logic family and AEC-Q100 qualified for automotive applications. It features two channels with Schmitt-trigger inputs, providing excellent noise immunity and signal conditioning. The push-pull outputs can source and sink 32mA, driving loads directly. Operating from 1.65V to 5.5V, it supports a wide range of logic levels. Housed in a compact 6-pin SOT-363 package, it is ideal for space-constrained automotive ECUs, sensor interfaces, and portable electronics where reliable signal integrity is critical.
- AEC-Q100 Qualified: Meets automotive reliability standards for harsh environments.
- Schmitt-Trigger Inputs: Provides hysteresis for noise immunity and clean signal edges.
- Push-Pull Outputs: Drives loads directly without external pull-up resistors.
- Wide 1.65V to 5.5V Supply Range: Compatible with multiple logic levels.
- Compact SOT-363 Package: Saves valuable board space in automotive modules.
Automotive ECU Signal Conditioning
The SN74LVC2G17QDCKRQ1 is AEC-Q100 qualified, making it ideal for automotive ECUs. The Schmitt-trigger inputs clean up noisy signals from sensors and switches, ensuring reliable logic levels.
Noise-Immune Sensor Interfaces
Use this buffer to interface with sensors in industrial or automotive environments. The Schmitt-trigger action provides hysteresis, preventing false triggering due to electrical noise.
Push-Pull Output for Direct Load Driving
The push-pull outputs can directly drive LEDs, relays, or other moderate loads without external pull-up resistors. This simplifies circuit design and reduces component count.
Level Shifting in Mixed-Voltage Systems
With a 1.65V to 5.5V supply range, this buffer can shift signals between 1.8V, 2.5V, 3.3V, and 5V logic domains, making it versatile for multi-voltage designs.
Clock and Signal Buffering
Buffer clock signals or data lines with this IC to improve signal integrity. The Schmitt-trigger inputs ensure clean edges, reducing jitter and improving timing margins.
Portable and Battery-Powered Devices
In battery-powered devices, this buffer's low-voltage operation and small package make it ideal for signal conditioning while minimizing power consumption and board space.
- Q: What is the logic family of the SN74LVC2G17QDCKRQ1?
- A: It belongs to the 74LVC family, known for low-voltage, high-speed operation, and is AEC-Q100 qualified for automotive use.
- Q: What is the function of this IC?
- A: It is a dual (2-channel) non-inverting buffer with Schmitt-trigger inputs, providing noise immunity and signal conditioning.
- Q: What is the output type?
- A: The outputs are Push-Pull, providing strong drive and fast transitions without the need for pull-up resistors.
- Q: What is the operating voltage range?
- A: It operates from 1.65V to 5.5V, supporting both 3.3V and 5V systems.
- Q: What is the package type?
- A: It comes in a 6-pin SOT-363 (SC-88) package, ideal for space-constrained automotive modules.
- Q: What is the output current capability?
- A: It can source and sink 32mA, suitable for driving LEDs and other moderate loads.
