STMicroelectronics STM32H725REV6
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $26.73 | $26.73 |
| 15+ | $6.15 | $92.25 |
| 25+ | $6.01 | $150.25 |
| 50+ | $5.68 | $284.00 |
| 100+ | $5.01 | $501.00 |
| N+ | $1.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | STMicroelectronics |
| Product Series | STM32H7 |
| Packaging | Bulk | NULL |
| Core Processor | ARM® Cortex®-M7 |
| Core Size | 32-Bit |
| Speed | 550MHz |
| Connectivity | CANbus, EBI/EMI, I2C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT |
| Number of I/O | 46 |
| Program Memory Size | 512KB (512K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 564K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 3.6V |
| Data Converters | A/D 28x12/16b; D/A 2x12b |
| Oscillator Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 68-VFQFPN (8x8) |
| Package / Case | 68-VFQFN Exposed Pad |
| ROHS |  |
The STM32H725REV6 from STMicroelectronics is a high-performance MCU based on the ARM Cortex-M7 core, running at 550MHz. It provides 512KB of flash and 564KB of RAM, along with an LCD controller and advanced connectivity. Packaged in a 68-VFQFN, it targets demanding embedded applications.
- Exceptional Performance: 550MHz Cortex-M7 delivers industry-leading compute for MCUs.
- Large RAM: 564KB SRAM supports complex algorithms and large data buffers.
- Integrated LCD Controller: Enables direct GUI development without external display drivers.
- Rich Peripheral Set: Includes I2S, PWM, DMA, and multiple communication interfaces.
High-End Industrial HMI
The 550MHz Cortex-M7 core and LCD controller enable rich graphical user interfaces on industrial panels with smooth animations.
Edge AI Inference
With its high clock speed and DSP instructions, it can run small neural network models for predictive maintenance in smart factories.
Motor Control Drives
Advanced PWM timers and fast ADC conversion support field-oriented control of high-performance servo motors.
Medical Imaging Devices
The large RAM and processing power handle real-time image processing for portable ultrasound and endoscopy equipment.
Audio Processing Units
I2S and SAI interfaces combined with high-speed processing enable multi-channel audio effects in professional mixers.
Robotics Controllers
Its computational capability and rich peripherals make it ideal for complex kinematics and sensor fusion in collaborative robots.
- Q: What is the maximum clock speed?
- A: The STM32H725REV6 operates at up to 550MHz.
- Q: How much RAM is available?
- A: It features 564KB of SRAM.
- Q: What is the package type?
- A: It comes in a 68-pin VFQFN package with exposed pad.
- Q: Does it support LCD?
- A: Yes, it includes an LCD controller for direct display driving.
