3PEAK TPC5161-VS2R
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $7.50 | $7.50 |
| 15+ | $7.26 | $108.90 |
| 25+ | $7.10 | $177.50 |
| 50+ | $6.71 | $335.50 |
| 100+ | $5.92 | $592.00 |
| N+ | $1.18 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | 3PEAK |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 600k |
| Number of Inputs | 1 |
| Input Type | Pseudo-Differential |
| Data Interface | SPI |
| Configuration | ADC |
| Ratio - S/H:ADC | 0:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 4.5V ~ 5.5V |
| Voltage - Supply, Digital | 1.8V ~ 5V |
| Features | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 10-MSOP |
| ROHS |  |
The TPC5161-VS2R from 3PEAK is a high-precision 16-bit analog-to-digital converter (ADC) with a maximum sampling rate of 600 kSPS. This single-channel device uses an SPI interface for communication and requires an external voltage reference for accurate conversions. It is housed in a compact 10-TFSOP/10-MSOP package and operates over a wide temperature range of -40°C to +125°C. The high resolution makes it ideal for precision measurement, medical, and industrial applications where accuracy is paramount.
- 16-Bit High Resolution: Provides exceptional accuracy with 65,536 levels, ideal for precision measurement applications.
- Wide Temperature Range: -40°C to +125°C ensures reliable performance in harsh automotive and industrial environments.
- Compact Package: The 10-TFSOP/MSOP package minimizes PCB footprint, suitable for space-constrained designs.
- Fast Sampling: 600 kSPS throughput supports real-time data acquisition in dynamic systems.
High-Precision Industrial Measurement
The 16-bit resolution and 600 kSPS sampling rate make the TPC5161-VS2R ideal for precision industrial measurement systems such as weigh scales, pressure transmitters, and temperature controllers.
Medical Diagnostic Equipment
In medical devices like blood analyzers and patient monitors, the high resolution ensures accurate digitization of small biosignals, improving diagnostic accuracy.
Scientific Instrumentation
For laboratory equipment such as spectrometers and data loggers, the 16-bit accuracy and SPI interface enable precise data capture and easy integration with digital systems.
Energy Monitoring and Metering
The high resolution allows accurate measurement of voltage and current in energy metering applications, supporting precise power quality analysis.
Automotive Sensor Conditioning
With a wide temperature range of -40°C to +125°C, this ADC is suitable for automotive sensor interfaces, including exhaust gas sensors and motor control feedback.
Audio and Vibration Analysis
The 600 kSPS rate and 16-bit resolution are sufficient for high-fidelity audio and vibration analysis in industrial condition monitoring systems.
- Q: What is the TPC5161-VS2R?
- A: It is a 16-bit analog-to-digital converter (ADC) with a standard ADC architecture, designed for high-precision applications.
- Q: What is the resolution?
- A: It provides 16-bit resolution, offering 65,536 discrete levels for highly accurate signal conversion.
- Q: What is the maximum sampling rate?
- A: The maximum sampling rate is 600 kSPS (kilo samples per second).
- Q: How many channels does it have?
- A: It has a single input channel (1 channel).
- Q: What interface does it use?
- A: It uses the SPI (Serial Peripheral Interface) for digital communication.
- Q: What is the operating temperature range?
- A: It operates over -40°C to +125°C and is available in a 10-TFSOP/10-MSOP package.
