Torex Semiconductor Ltd XC6220B301PR-G
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.82 | $1.82 |
| 15+ | $0.41 | $6.15 |
| 25+ | $0.41 | $10.25 |
| 50+ | $0.38 | $19.00 |
| 100+ | $0.34 | $34.00 |
| N+ | $0.07 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Torex Semiconductor Ltd |
| Product Series | |
| Packaging | Tape & Reel (TR) | |
| Output Configuration | Active |
| Output Type | Positive |
| Number of Regulators | Fixed |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Min/Fixed) | 3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.655V @ 1A |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 18 μA |
| Current - Supply (Max) | 108 μA |
| PSRR | 50dB (1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-89-5/6 |
| Supplier Device Package | SOT-89-5 |
| ROHS |  |
The Torex XC6220B301PR-G is a high-performance fixed-output LDO regulator providing a stable 3.0V supply. Capable of delivering up to 1A of current with a low dropout voltage of 0.655V, it is designed for power-hungry applications that require efficiency and reliability. The SOT-89-5 package ensures good thermal performance, while the 18 μA quiescent current and 50dB PSRR make it suitable for both battery-powered and noise-sensitive electronic systems.
- High Current Capacity: Supports up to 1A output, ideal for powering processors and peripherals.
- Low Dropout Voltage: 0.655V dropout at 1A maximizes efficiency by allowing operation with minimal input-to-output voltage difference.
- Excellent Noise Rejection: 50dB PSRR at 1kHz ensures clean power for sensitive analog and RF circuits.
- Balanced Efficiency: 18 μA quiescent current provides a good trade-off between performance and power saving.
High-Current FPGA/ASIC Power
The 1A output capability and low dropout of 0.655V make the XC6220B301PR-G suitable for powering core voltages of FPGAs and ASICs in networking equipment, ensuring stable 3.0V operation.
Automotive Infotainment Systems
With a robust SOT-89-5 package and 1A current rating, this regulator can supply clean 3.0V power to infotainment processors and display controllers, maintaining performance under varying load conditions.
Industrial Sensor Interfaces
Provide a stable 3.0V rail for industrial sensors and transceivers, where the 50dB PSRR at 1kHz helps reject power supply noise from motors and actuators.
Telecom Base Stations
Use the XC6220B301PR-G to power RF transceiver modules, benefiting from its high current capacity and low quiescent current to maintain signal integrity and efficiency.
Portable Power Banks
In battery charging and management circuits, this LDO can regulate a 3.0V logic supply for control ICs, with the low dropout ensuring efficient use of battery voltage.
Medical Monitoring Equipment
For patient monitors requiring reliable 3.0V power, this regulator offers the current headroom and low noise performance needed for sensitive analog front-ends.
- Q: What is the output voltage of the XC6220B301PR-G?
- A: This LDO provides a fixed 3.0V output voltage.
- Q: What is the maximum output current?
- A: The XC6220B301PR-G can deliver up to 1A of output current.
- Q: What is the input voltage range?
- A: The input voltage range is from 3.0V up to the maximum rated input; consult the datasheet for the absolute maximum.
- Q: What is the dropout voltage?
- A: The dropout voltage is 0.655V at a 1A load, allowing efficient operation with low headroom.
- Q: What is the quiescent current?
- A: The quiescent current is 18 μA, balancing performance with power efficiency.
- Q: What package is available?
- A: It is available in the SOT-89-5 surface-mount package.
