Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Texas Instruments
SN74LV4053ADYYR
Integrated Circuits & Chips
Texas Instruments
IC SW 5V 2:1 (SPDT) THREE-CHANNEL ANAL
SN74LV4053ADYYR
Regular price
$0.18
(Volume discounts available! Contact our customer support for customized pricing on bulk orders.Pro Tip: 🇺🇸 Switch your region to United States for localized offers.)
(Volume discounts available! Contact our customer support for customized pricing on bulk orders.Pro Tip: 🇺🇸 Switch your region to United States for localized offers.)
Regular price
$0.19
Sale price
Unit price
per
| quantity | unit price | total price |
| 1 | $0.18 | $0.18 |
| 15+ | $0.17 USD | $2.62 USD |
| 25+ | $0.17 USD | $4.28 USD |
| 50+ | $0.16 USD | $8.08 USD |
| 100+ | $0.14 USD | $14.25 USD |
| N+ | $0.10 USD | Price Inquiry |
Shipping calculated at checkout.
Couldn't load pickup availability
Apply for PCBA engineering assistance
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | 74LV |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Switch Circuit | SPDT - Open/Closed |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Circuits | 3 |
| On-State Resistance (Max) | 75Ohm |
| Channel-to-Channel Matching (ΔRon) | 1.3Ohm |
| Voltage - Supply, Single (V+) | 1V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 14ns, 14ns |
| -3db Bandwidth | - |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 2pF, 23pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Crosstalk | -45dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-16 Thin, SOT-23 Variant |
| Supplier Device Package | 16-SOT-23-THIN |
Datasheets:
SN74LV4053ADYYR
.pdf
×
