Analog Devices Inc. 5962-87591023X
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $782.92 | $782.92 |
| 15+ | $180.07 | $2,701.05 |
| 25+ | $176.16 | $4,404.00 |
| 50+ | $166.37 | $8,318.50 |
| 100+ | $146.80 | $14,680.00 |
| N+ | $29.36 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | - |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | Parallel |
| Configuration | MUX-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | Internal |
| Voltage - Supply, Analog | -14.25V ~ -15.75V, 4.75V ~ 5.25V |
| Voltage - Supply, Digital | -14.25V ~ -15.75V, 4.75V ~ 5.25V |
| Features | - |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 28-CLCC |
| Supplier Device Package | 28-CLCC (11.43x11.43) |
The 5962-87591023X from Analog Devices is a high-reliability 12-bit analog-to-digital converter designed for demanding applications. Featuring a single input channel and a parallel interface, this MUX-ADC architecture ensures efficient data transfer. With an internal reference and military-grade temperature range, it delivers consistent performance in extreme conditions. Its 28-CLCC package is ideal for aerospace, defense, and industrial control systems where precision and durability are paramount.
- Military-Grade Reliability: Operates from -55°C to 125°C, ensuring functionality in extreme environments.
- Integrated MUX-ADC: Combines multiplexing and conversion in one device, simplifying board design.
- Internal Reference: Reduces external component count and improves system accuracy.
- Parallel Output: Enables fast, straightforward interfacing with legacy and modern digital systems.
Military & Aerospace Data Acquisition
The 12-bit resolution and wide -55°C to 125°C temperature range make this ADC suitable for avionics and defense systems requiring reliable performance in extreme environments.
Industrial Process Control
With its internal reference and parallel interface, this converter can digitize sensor outputs in industrial automation systems where deterministic timing and high accuracy are critical.
Precision Instrumentation
The MUX-ADC architecture allows for efficient signal routing in bench-top and portable test equipment, ensuring accurate measurement of DC or low-frequency AC signals.
Medical Monitoring Devices
Its single-channel design and 12-bit precision support vital sign monitoring systems that require stable, low-noise conversion of biological signals.
High-Reliability Embedded Systems
The 28-CLCC package provides a hermetic seal, protecting the internal circuitry from moisture and contaminants in harsh industrial or defense environments.
- Q: What is the resolution of the 5962-87591023X ADC?
- A: This Analog Devices ADC features 12-bit resolution, providing 4096 discrete output levels for precise signal digitization.
- Q: How many input channels does this ADC support?
- A: It has a single (1) input channel, making it ideal for dedicated, high-accuracy single-signal conversion applications.
- Q: What interface does the 5962-87591023X use?
- A: It utilizes a parallel interface for high-speed data transfer to microcontrollers or DSPs.
- Q: What is the architecture of this converter?
- A: It uses a MUX-ADC architecture, integrating a multiplexer with the analog-to-digital conversion core.
- Q: What is the operating temperature range?
- A: It is rated for military-grade temperatures from -55°C to 125°C.
- Q: What package is available?
- A: It comes in a 28-CLCC (Ceramic Leadless Chip Carrier) package.
