Renesas Electronics Corporation 5P1105A000NLGI
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $4.40 | $4.40 |
| 15+ | $4.26 | $63.90 |
| 25+ | $4.17 | $104.25 |
| 50+ | $3.94 | $197.00 |
| 100+ | $3.47 | $347.00 |
| N+ | $0.69 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Renesas Electronics Corporation |
| Product Series | |
| Packaging | Tray | |
| Type | - |
| PLL | No |
| Input | HCSL, LVCMOS, LVDS, LVPECL, Crystal |
| Output | HCSL, LVCMOS, LVDS, LVPECL |
| Number of Circuits | 1 |
| Ratio - Input:Output | 2:4 |
| Differential - Input:Output | Yes/Yes |
| Frequency - Max | 350MHz |
| Divider/Multiplier | No/No |
| Voltage - Supply | 1.71V ~ 3.465V |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 24-VFQFN Exposed Pad |
| Supplier Device Package | 24-QFN (4x4) |
| ROHS |  |
The 5P1105A000NLGI from Renesas Electronics Corporation is a versatile clock IC supporting a wide range of input and output standards including HCSL, LVCMOS, LVDS, LVPECL, and Crystal. With a single circuit capable of operating up to 350MHz, it provides flexible timing solutions for high-speed digital systems. Housed in a 24-VFQFN Exposed Pad package and rated for -40°C to 85°C, it is designed for demanding networking, telecom, and industrial applications.
- Multi-Standard Support: Accepts and outputs HCSL, LVCMOS, LVDS, and LVPECL signals, providing maximum design flexibility for mixed-logic systems.
- High-Frequency Operation: Supports up to 350MHz, making it suitable for high-speed data communication and processing applications.
- Wide Temperature Range: Rated for -40°C to 85°C, ensuring reliable operation in industrial and outdoor environments.
- Compact QFN Package: The 24-VFQFN package with exposed pad offers excellent thermal performance and a small footprint for space-constrained designs.
High-Speed Networking Timing
With support for multiple differential I/O standards (HCSL, LVDS, LVPECL) and a 350MHz maximum frequency, this device is ideal for clock distribution in high-speed networking switches, routers, and line cards.
Telecom Infrastructure
The flexible input/output configuration allows it to interface with various telecom clock sources and generate the required output formats for base stations, backhaul equipment, and optical transport systems.
Data Center and Server Clocks
Its ability to handle LVCMOS and differential signals makes it suitable for generating and distributing clocks in servers, storage systems, and data center switches where signal integrity is critical.
Broadcast Video Synchronization
The 350MHz capability and multiple output types enable use in professional broadcast equipment for synchronizing video processing, encoding, and transmission systems.
Industrial Automation Control
The wide temperature range and robust signal standards make it suitable for industrial automation controllers, PLCs, and motion control systems requiring precise, high-speed timing.
FPGA and ASIC Clocking
This device can provide the multiple clock formats needed to drive FPGAs and ASICs in prototyping and production systems, simplifying board design by supporting various logic families.
- Q: What type of device is the 5P1105A000NLGI?
- A: The 5P1105A000NLGI is a clock IC from Renesas Electronics Corporation, though the specific type is not listed in the provided data.
- Q: Does the 5P1105A000NLGI include a PLL?
- A: No, the technical data indicates that this device does not have a PLL.
- Q: What input types does it support?
- A: It supports HCSL, LVCMOS, LVDS, LVPECL, and Crystal inputs.
- Q: What output types are available?
- A: It provides HCSL, LVCMOS, LVDS, and LVPECL outputs.
- Q: How many circuits does it have and what is the maximum frequency?
- A: It has 1 circuit and supports a maximum frequency of 350MHz.
- Q: What is the package type?
- A: It is available in a 24-VFQFN Exposed Pad package.
