Renesas Electronics Corporation 5P49EE805NDGI
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Renesas Electronics Corporation |
| Product Series | VersaClock® |
| Packaging | | |
| Type | - |
| PLL | Yes with Bypass |
| Input | LVTTL, Crystal |
| Output | LVCMOS, LVTTL |
| Number of Circuits | 1 |
| Ratio - Input:Output | 2:8 |
| Differential - Input:Output | No/No |
| Frequency - Max | 100MHz |
| Divider/Multiplier | Yes/No |
| Voltage - Supply | 1.71V ~ 3.465V |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 28-VQFN Exposed Pad |
| Supplier Device Package | 28-VFQFPN (6x6) |
| ROHS |  |
The Renesas 5P49EE805NDGI is a flexible clock generator featuring a PLL with bypass for adaptable timing. With one circuit supporting up to 100MHz, it accepts LVTTL or crystal inputs and outputs LVCMOS/LVTTL signals. Housed in a 28-VQFN package, it is ideal for networking, telecom, and industrial applications requiring reliable clock synthesis.
- PLL with Bypass: Offers both frequency multiplication and direct input passthrough for design flexibility.
- Multiple Input Options: Supports LVTTL and crystal, accommodating various reference sources.
- Industrial Temperature: -40°C to 85°C for harsh environments.
- Compact VQFN Package: Saves board space while providing robust thermal performance.
Networking Timing
Generate clocks for Ethernet switches and routers, using the PLL to multiply crystal frequencies to required rates.
Processor Clocking
Provide core and I/O clocks to embedded processors, with bypass mode for direct external clocking.
Telecom Infrastructure
Clock line cards and base stations, ensuring reliable timing in critical communication systems.
Industrial Automation
Supply timing signals for PLCs and robotics, with robust operation over the industrial temperature range.
Broadcast Video
Generate pixel clocks for video processors and encoders, maintaining synchronization in broadcast chains.
- Q: What type of device is the 5P49EE805NDGI?
- A: It is a clock generator IC from Renesas, designed for versatile timing solutions.
- Q: Does the 5P49EE805NDGI support PLL?
- A: Yes, it includes a PLL with bypass, allowing both synthesized and direct clock generation.
- Q: What are the input and output types?
- A: It accepts LVTTL and Crystal inputs, and provides LVCMOS and LVTTL outputs.
- Q: How many circuits and what is the max frequency?
- A: It has 1 circuit and supports a maximum frequency of 100MHz.
- Q: What is the package and temperature range?
- A: It comes in a 28-VQFN Exposed Pad package and operates from -40°C to 85°C.
