Altera 5SGXMA7K3F40I3NCV

Product Overview

The Altera 5SGXMA7K3F40I3NCV is a high-performance Field Programmable Gate Array (FPGA) from the Stratix V GX family, engineered for demanding embedded and industrial applications requiring exceptional processing power and reliability. With an impressive 622,000 logic elements and 51.2 megabits of embedded RAM, this FPGA delivers unmatched flexibility and computational capacity for complex digital designs, real-time signal processing, and mission-critical systems.

Built on advanced 28nm process technology, the Stratix V GX architecture combines high-speed transceivers, abundant logic resources, and extensive memory blocks to enable sophisticated system implementations. The device's industrial-grade temperature range and robust design make it ideal for harsh operating environments where reliability is paramount.

Key Features & Technical Advantages

• 622,000 Logic Elements: Massive logic capacity enables implementation of complex algorithms, multiple processing cores, and sophisticated control systems in a single device
• 696 I/O Pins: Extensive connectivity options provide flexible interfacing with external devices, memory systems, sensors, and communication protocols
• 51.2 Mb Embedded RAM: High-speed on-chip memory blocks support data buffering, packet processing, image processing, and high-throughput applications
• 234,720 LABs/CLBs: Abundant configurable logic blocks deliver exceptional design flexibility and resource utilization
• Industrial Temperature Range: Operates reliably from -40°C to 100°C (TJ), ensuring stable performance in extreme environmental conditions
• 1517-FBGA Package (40x40mm): Compact fine-pitch ball grid array optimized for space-constrained designs while maintaining excellent thermal performance
• Surface Mount Technology: Compatible with automated assembly processes for high-volume manufacturing and improved reliability
• 0.82V ~ 0.88V Supply Voltage: Low-voltage operation reduces power consumption while maintaining high performance

Performance Capabilities

The Stratix V GX FPGA architecture delivers industry-leading performance for bandwidth-intensive applications. The device's high-speed transceivers, combined with abundant logic and memory resources, enable implementation of advanced DSP algorithms, high-speed networking protocols, video processing pipelines, and parallel computing architectures. The extensive I/O capabilities support multiple high-speed interfaces simultaneously, making it ideal for systems requiring diverse connectivity options.

Applications & Use Cases

This Stratix V GX FPGA excels in a wide range of demanding applications:

• High-Performance Computing: Accelerate computational workloads, scientific simulations, and data analytics
• Telecommunications Infrastructure: Implement baseband processing, protocol conversion, and network packet processing
• Industrial Automation: Control complex machinery, robotics systems, and real-time monitoring applications
• Medical Imaging Systems: Process ultrasound, CT, MRI, and X-ray imaging data with low latency
• Aerospace & Defense: Radar signal processing, secure communications, and mission-critical control systems
• Advanced Signal Processing: Software-defined radio, beamforming, and multi-channel data acquisition
• Video Processing & Broadcasting: Real-time video encoding, transcoding, and format conversion
• Test & Measurement Equipment: High-speed data capture, protocol analysis, and signal generation

Design & Integration Benefits

Engineers choosing the 5SGXMA7K3F40I3NCV benefit from Altera's comprehensive development ecosystem, including Quartus Prime design software, IP cores, and reference designs. The device's abundant resources allow for future design expansion without hardware changes, protecting your investment and reducing time-to-market for product updates. The industrial-grade qualification ensures long-term reliability in production environments.

Quality Assurance & Authenticity

All FPGAs are sourced exclusively through authorized distribution channels with complete traceability and comprehensive lifecycle support. Each component undergoes rigorous quality inspection and authentication testing to ensure 100% genuine Altera products. We provide full documentation, including datasheets, compliance certificates, and traceability records for your critical applications. Our commitment to authentic sourcing protects your designs from counterfeit components and ensures consistent performance across production runs.

Technical Support & Lifecycle Management

We provide comprehensive technical support throughout your product lifecycle, including design consultation, obsolescence management, and long-term availability planning. Our team of semiconductor specialists can assist with device selection, migration planning, and supply chain optimization to ensure uninterrupted production.

Package & Handling Information

The device is supplied in tray packaging, suitable for automated pick-and-place assembly. The 1517-FBGA package features a 40x40mm footprint with fine-pitch ball grid array for high-density PCB layouts. Proper ESD handling procedures and moisture sensitivity level (MSL) precautions should be observed during storage and assembly.
