Renesas Electronics Corporation 5V49EE701-075NDGI8
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Renesas Electronics Corporation |
| Product Series | VersaClock® III |
| Packaging | | |
| Type | Clock Generator, Multiplexer |
| PLL | Yes with Bypass |
| Input | LVCMOS, LVTTL, Crystal |
| Output | HCSL, LVCMOS, LVDS, LVPECL, LVTTL |
| Number of Circuits | 1 |
| Ratio - Input:Output | 2:6 |
| Differential - Input:Output | No/Yes |
| Frequency - Max | 500MHz |
| Divider/Multiplier | Yes/Yes |
| Voltage - Supply | 3.135V ~ 3.465V |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 28-VFQFN Exposed Pad |
| Supplier Device Package | 28-QFN (4x4) |
| ROHS |  |
The Renesas 5V49EE701-075NDGI8 is a versatile clock generator and multiplexer designed for high-performance timing applications. It integrates a PLL with bypass, supporting a wide range of input and output signal types including LVCMOS, LVDS, and LVPECL. With a maximum output frequency of 500MHz and a single circuit, this device is ideal for telecom, networking, and industrial systems requiring flexible, low-jitter clock synthesis.
- High Flexibility: Supports multiple I/O standards (HCSL, LVDS, LVPECL) enabling use in diverse system architectures.
- Reliable Operation: Wide temperature range (-40°C to 85°C) ensures performance in harsh industrial environments.
- Integrated PLL with Bypass: Allows both frequency synthesis and direct clock distribution, simplifying design.
- Compact Package: 28-VFQFN package saves board space for dense designs.
Telecom Clock Generation
Generate precise 500MHz clocks for telecom line cards and switches, leveraging the PLL with bypass for flexible frequency synthesis and jitter cleanup.
Networking Equipment Timing
Provide multiple output formats (HCSL, LVDS, LVPECL) from a single device to synchronize Ethernet switches, routers, and optical modules, reducing component count.
Processor and FPGA Clocking
Supply low-jitter reference clocks to high-performance processors and FPGAs, using the multiplexer to select between crystal and LVCMOS references for redundancy.
Broadcast Video Synchronization
Generate synchronized clocks for video processing chains, ensuring frame-accurate timing across multiple channels with the 500MHz capability.
Industrial Automation Timing
Deliver robust clock signals in industrial controllers and PLCs, operating reliably across the -40°C to 85°C temperature range.
Test and Measurement Instruments
Create stable, programmable clock sources for signal generators and analyzers, utilizing the versatile output types to interface with various test modules.
- Q: What type of device is the 5V49EE701-075NDGI8?
- A: It is a Clock Generator with Multiplexer functionality from Renesas.
- Q: Does it support PLL?
- A: Yes, it has a PLL with bypass capability.
- Q: What are the input and output types?
- A: Inputs support LVCMOS, LVTTL, and Crystal. Outputs support HCSL, LVCMOS, LVDS, LVPECL, and LVTTL.
- Q: How many circuits does it have?
- A: It has 1 circuit.
- Q: What is the maximum frequency?
- A: The maximum frequency is 500MHz.
- Q: What is the operating temperature and package?
- A: It operates from -40°C to 85°C and comes in a 28-VFQFN Exposed Pad package.
