onsemi 74LVX541MTC
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.36 | $1.36 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | onsemi |
| Product Series | 74LVX |
| Packaging | | |
| Part Status | Obsolete |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 1 |
| Number of Bits per Element | 8 |
| Input Type | - |
| Output Type | 3-State |
| Current - Output High, Low | 4mA, 4mA |
| Voltage - Supply | 2V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 20-TSSOP |
| ROHS |  |
The 74LVX541MTC is a single-channel non-inverting buffer from Fairchild Semiconductor, part of the 74LVX logic family. It operates at a supply voltage of 2V to 3.6V and provides 3-State outputs for bus-oriented applications. Each output can source or sink 4mA, making it suitable for driving moderate loads. The 20-TSSOP package is compact for space-constrained designs. Typical applications include 3.3V bus interfacing, signal buffering, and level shifting in low-power digital systems.
- Low-Voltage Operation (2V-3.6V): Ideal for modern low-power, battery-operated devices.
- Non-Inverting Output: Preserves signal polarity, simplifying logic design.
- 3-State Outputs: Enables bus sharing and multiplexing, reducing component count.
- Compact TSSOP Package: Saves board space in high-density designs.
3.3V Bus Interfacing
Use the 74LVX541MTC to buffer non-inverted signals in 3.3V systems, ensuring clean signal propagation on data buses.
Low-Power Portable Devices
Operate at low voltages (2V-3.6V) to minimize power consumption in battery-powered devices like smartphones and wearables.
Memory Data Bus Buffering
Buffer data lines between memory and controllers, maintaining signal integrity with 3-State outputs for bus sharing.
Peripheral Driver Isolation
Isolate sensitive logic from peripheral loads, providing buffered outputs that prevent back-drive and signal corruption.
FPGA Signal Distribution
Distribute FPGA output signals to multiple destinations with buffered, non-inverted outputs, ensuring consistent logic levels.
Consumer Electronics Interface
In TVs and gaming consoles, buffer control signals between main processors and peripheral interfaces, ensuring reliable operation.
- Q: What logic family does the 74LVX541MTC belong to?
- A: It belongs to the 74LVX logic family, which is low-voltage CMOS operating from 2V to 3.6V.
- Q: What is the function of this IC?
- A: It is a non-inverting buffer with 1 channel, providing signal buffering without inversion.
- Q: What is the output type?
- A: It features 3-State outputs, allowing connection to shared buses with high-impedance states.
- Q: What is the voltage range?
- A: The supply voltage range is 2V to 3.6V, ideal for low-voltage 3.3V systems.
- Q: What is the output current capability?
- A: It can source or sink 4mA per output.
- Q: What package is available?
- A: It comes in a 20-TSSOP package (0.173", 4.40mm Width).
