Analog Devices Inc. AD674BKNZ
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $84.46 | $84.46 |
| 15+ | $81.80 | $1,227.00 |
| 25+ | $80.02 | $2,000.50 |
| 50+ | $75.57 | $3,778.50 |
| 100+ | $66.68 | $6,668.00 |
| N+ | $13.34 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | - |
| Number of Inputs | 2 |
| Input Type | Single Ended |
| Data Interface | Parallel |
| Configuration | ADC |
| Ratio - S/H:ADC | - |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | ±11.4V ~ 16.5V |
| Voltage - Supply, Digital | 5V |
| Features | - |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Grade | - |
| Qualification | - |
| Package / Case | 28-DIP (0.600", 15.24mm) |
| Supplier Device Package | 28-PDIP |
| ROHS |  |
The AD674BKNZ is a 12-bit, dual-channel analog-to-digital converter from Analog Devices. It features a parallel interface and a standard ADC architecture. The external/internal reference options provide design flexibility. This ADC is suitable for industrial control, educational, and low-speed data logging applications. The 28-DIP package is ideal for through-hole PCB designs and prototyping.
- Dual-Channel Input: Allows simultaneous monitoring of two analog signals, useful for battery monitoring or stereo audio.
- Parallel Interface: Simple and direct connection to microcontrollers and digital systems.
- DIP Package: Easy to handle and solder, ideal for prototyping and educational use.
- Flexible Reference: Supports both external and internal references for design flexibility.
Legacy Industrial Control Systems
The AD674BKNZ is suitable for upgrading or maintaining legacy industrial control systems that require a 12-bit parallel ADC. Its DIP package is easy to handle in through-hole PCB designs.
Educational Laboratory Equipment
Use this ADC in educational settings to teach analog-to-digital conversion principles. The parallel interface and DIP package make it ideal for breadboard prototyping.
Simple Data Logging
For low-speed data logging applications where sampling rate is not critical, the AD674BKNZ provides a simple, reliable solution with its parallel interface.
Audio Processing (Low-Speed)
In applications like voice band processing, the 12-bit resolution is sufficient for basic audio digitization. The dual channels can handle stereo signals.
Battery Monitoring Systems
Monitor voltage and current of batteries with the dual-channel input. The 0°C to 70°C temperature range is suitable for indoor and commercial environments.
- Q: What is the resolution of the AD674BKNZ?
- A: It is a 12-bit analog-to-digital converter.
- Q: What is the sampling rate?
- A: The technical data does not specify a sampling rate for this ADC.
- Q: How many channels does it have?
- A: This ADC has 2 input channels.
- Q: What interface does it use?
- A: It uses a parallel interface.
- Q: What is the architecture?
- A: It uses a standard ADC architecture.
- Q: What is the package type?
- A: It comes in a 28-DIP (0.600", 15.24mm) package.
