Texas Instruments ADC12D1000RFIUT/NOPB
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1,515.24 | $1,515.24 |
| 15+ | $1,467.39 | $22,010.85 |
| 25+ | $1,435.49 | $35,887.25 |
| 50+ | $1,355.74 | $67,787.00 |
| 100+ | $1,196.24 | $119,624.00 |
| N+ | $239.25 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Tray | |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 2G |
| Number of Inputs | 2 |
| Input Type | Differential |
| Data Interface | LVDS - Parallel |
| Configuration | MUX-S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 2 |
| Architecture | Folding Interpolating |
| Reference Type | Internal |
| Voltage - Supply, Analog | 1.8V ~ 2V |
| Voltage - Supply, Digital | 1.8V ~ 2V |
| Features | Simultaneous Sampling |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 292-BBGA |
| Supplier Device Package | 292-BGA (27x27) |
| ROHS |  |
The ADC12D1000RFIUT/NOPB is a high-speed 12-bit, 2-channel analog-to-digital converter from Texas Instruments, delivering a sampling rate of 2 GSPS. Its MUX-S/H-ADC architecture ensures excellent dynamic performance. The LVDS parallel interface provides a simple, high-speed connection to FPGAs and DSPs. With an internal reference and robust 292-BBGA package, this ADC is designed for demanding applications in test and measurement, radar, and communications.
- High Sampling Rate: 2 GSPS enables capture of wideband signals with high fidelity.
- Dual-Channel Operation: Supports simultaneous sampling for I/Q or diversity applications.
- LVDS Interface: Provides low-noise, high-speed data transfer with reduced EMI.
- Integrated Reference: Simplifies design and improves accuracy.
High-Performance Oscilloscopes
The 2 GSPS sampling rate and 12-bit resolution enable high-fidelity capture of fast transient signals in digital storage oscilloscopes.
Radar Signal Processing
Dual-channel operation supports I/Q demodulation in radar receivers, improving target discrimination.
Communications Receivers
LVDS parallel interface provides low-latency data transfer for real-time communication systems.
Spectrum Analysis
Wide bandwidth and high resolution make it suitable for spectrum analyzers covering up to 1 GHz of instantaneous bandwidth.
Medical Imaging
Used in high-end ultrasound and MRI systems where precise signal digitization is critical.
Scientific Research
Ideal for particle physics and astronomy experiments requiring high-speed data acquisition.
- Q: What is the ADC12D1000RFIUT/NOPB?
- A: It is a 12-bit, 2-channel analog-to-digital converter from Texas Instruments.
- Q: What is the sampling rate?
- A: The sampling rate is 2 GSPS.
- Q: What interface does it use?
- A: It uses an LVDS parallel interface.
- Q: What is the ADC architecture?
- A: It uses a MUX-S/H-ADC architecture.
- Q: Does it have an internal reference?
- A: Yes, it has an internal reference.
- Q: What package is it available in?
- A: It comes in a 292-BBGA package.
