Analog Devices Inc. ADF4113HVBRUZ-RL
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $8.68 | $8.68 |
| 15+ | $8.41 | $126.15 |
| 25+ | $8.23 | $205.75 |
| 50+ | $7.77 | $388.50 |
| 100+ | $6.86 | $686.00 |
| N+ | $1.37 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Type | Clock/Frequency Synthesizer (RF) |
| PLL | Yes |
| Input | CMOS, TTL |
| Output | Clock |
| Number of Circuits | 1 |
| Ratio - Input:Output | 2:1 |
| Differential - Input:Output | Yes/No |
| Frequency - Max | 4GHz |
| Divider/Multiplier | Yes/No |
| Voltage - Supply | 2.7V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
| ROHS |  |
The ADF4113HVBRUZ-RL from Analog Devices is a high-performance Clock/Frequency Synthesizer (RF) featuring an integrated PLL for generating frequencies up to 4GHz. This single-circuit device accepts CMOS or TTL inputs and provides a clock output, making it ideal for RF local oscillator applications. Housed in a compact 16-TSSOP package, it operates over -40°C to 85°C, ensuring reliable performance in demanding wireless infrastructure, satellite, and test equipment environments.
- Ultra-High Frequency: Supports up to 4GHz, enabling use in advanced RF and microwave applications.
- Integrated PLL: Simplifies system design by providing a complete frequency synthesis solution on-chip.
- Wide Temperature Range: -40°C to 85°C operation ensures reliability in harsh industrial and outdoor environments.
- Compact TSSOP Package: The 16-TSSOP footprint saves PCB space while maintaining high performance.
High-Frequency Local Oscillator Generation
The ADF4113HVBRUZ-RL, with its PLL and 4GHz capability, generates precise local oscillator signals for microwave point-to-point radios, enabling reliable data transmission in backhaul networks.
Satellite Communication Systems
Its high-frequency output and CMOS/TTL inputs make it suitable for satellite transceivers, providing stable LO signals for up/down converters in C-band and Ku-band applications.
Test and Measurement Equipment
In spectrum analyzers and signal generators, this synthesizer delivers the required frequency agility and stability for generating test signals up to 4GHz, enabling accurate characterization of RF components.
Radar Systems
Its fast settling time and wide frequency range make it ideal for frequency-agile radar systems, enabling rapid frequency changes for target detection and tracking.
Wireless Infrastructure
Used in remote radio heads (RRHs) and distributed antenna systems (DAS), the ADF4113HVBRUZ-RL ensures synchronized clocking and frequency generation for multi-band wireless networks.
Aerospace and Defense
Its rugged design and wide temperature range make it suitable for military communication systems, electronic warfare, and avionics requiring reliable frequency synthesis.
- Q: What type of device is the ADF4113HVBRUZ-RL?
- A: It is a Clock/Frequency Synthesizer (RF) designed for high-frequency RF applications.
- Q: Does the ADF4113HVBRUZ-RL include a PLL?
- A: Yes, it includes a Phase-Locked Loop (PLL) for frequency synthesis.
- Q: What are the input and output types?
- A: The input types are CMOS and TTL. The output type is Clock.
- Q: How many circuits does it have and what is the maximum frequency?
- A: It has 1 circuit and can operate at frequencies up to 4GHz.
- Q: What is the operating temperature range?
- A: It operates over an industrial temperature range of -40°C to 85°C.
- Q: What is the package type?
- A: It comes in a 16-TSSOP (0.173", 4.40mm Width) package.
