Texas Instruments ADS6243IRGZT
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $84.46 | $84.46 |
| 15+ | $81.79 | $1,226.85 |
| 25+ | $80.01 | $2,000.25 |
| 50+ | $75.57 | $3,778.50 |
| 100+ | $66.68 | $6,668.00 |
| N+ | $13.34 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Marketplace | Cut Tape (CT) |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 80M |
| Number of Inputs | 2 |
| Input Type | Differential |
| Data Interface | LVDS - Serial |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 2 |
| Architecture | Pipelined |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 3V ~ 3.6V |
| Voltage - Supply, Digital | 3V ~ 3.6V |
| Features | Simultaneous Sampling |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 48-VFQFN Exposed Pad |
| Supplier Device Package | 48-VQFN (7x7) |
| ROHS |  |
The ADS6243IRGZT is a 14-bit dual-channel Analog-to-Digital Converter from Texas Instruments, designed for high-speed signal processing. With an impressive sampling rate of 80M SPS, it captures fast-changing signals with excellent fidelity. The two input channels enable simultaneous sampling, ideal for I/Q or stereo applications. The LVDS serial interface ensures high-speed data transfer with low noise. Packaged in a compact 48-VFQFN with exposed pad for thermal management, this ADC is perfect for communications, medical imaging, and test equipment.
- Ultra-High Sampling Rate: 80M SPS enables digitization of high-frequency signals for advanced applications.
- Dual-Channel Simultaneous Sampling: Perfect for I/Q processing and multi-sensor systems.
- LVDS Interface: Provides high-speed, low-noise data transfer to FPGAs or DSPs.
- Compact Package: 48-VFQFN with exposed pad aids thermal dissipation in dense designs.
High-Speed Dual-Channel I/Q Demodulation
The ADS6243IRGZT's dual 14-bit channels and 80M SPS sampling rate make it perfect for I/Q demodulation in software-defined radio (SDR) and radar systems.
Medical Ultrasound Imaging
In ultrasound machines, the dual-channel configuration allows simultaneous processing of in-phase and quadrature signals, improving image quality and frame rate.
Communications Receivers
For cellular base stations or point-to-point microwave links, this ADC digitizes IF signals with high speed and resolution, supporting advanced modulation schemes.
Test and Measurement
In high-bandwidth oscilloscopes or spectrum analyzers, the 80M SPS rate enables capture of fast signals with 14-bit dynamic range.
Industrial X-Ray Systems
The dual-channel capability supports simultaneous acquisition from two sensor arrays, increasing throughput in non-destructive testing equipment.
- Q: What is the ADS6243IRGZT?
- A: It is a 14-bit dual-channel Analog-to-Digital Converter (ADC) from Texas Instruments.
- Q: What is the resolution?
- A: It offers 14-bit resolution for accurate signal representation.
- Q: What is the sampling rate?
- A: It supports a high sampling rate of 80M SPS (80 million samples per second).
- Q: How many channels does it have?
- A: It has 2 input channels for simultaneous dual-channel acquisition.
- Q: What interface does it use?
- A: It uses an LVDS (Low-Voltage Differential Signaling) serial interface.
- Q: What is the package type?
- A: It comes in a 48-VFQFN Exposed Pad package.
