Burr Brown ADS826E-BB
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $71.36 | $71.36 |
| 15+ | $16.41 | $246.15 |
| 25+ | $16.06 | $401.50 |
| 50+ | $15.16 | $758.00 |
| 100+ | $13.38 | $1,338.00 |
| N+ | $2.68 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Burr Brown |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 10 |
| Sampling Rate (Per Second) | 60M |
| Number of Inputs | 1 |
| Input Type | Differential, Single Ended |
| Data Interface | Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | Pipelined |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) |
| Supplier Device Package | 28-SSOP |
| ROHS |  |
The ADS826E-BB from Burr Brown is a 10-bit, 60 MSPS single-channel analog-to-digital converter. With a parallel interface and sample-and-hold architecture, it provides high-speed conversion for demanding applications. Supporting both external and internal references, this ADC operates over -40°C to 85°C and is packaged in a compact 28-SSOP, making it ideal for video, communications, and industrial systems.
- Ultra-Fast Sampling: 60 MSPS rate captures high-frequency signals with minimal distortion.
- Flexible Reference: External or internal reference options provide design flexibility.
- Robust Temperature Range: -40°C to 85°C operation ensures performance in extreme conditions.
- Compact SSOP Package: 28-SSOP footprint saves PCB space in dense designs.
High-Speed Instrumentation
The 60 MSPS sampling rate enables precise digitization of fast transient signals in oscilloscopes and logic analyzers, ensuring accurate waveform reproduction.
Video Digitization
With 10-bit resolution and high speed, this ADC is suitable for digitizing composite video signals in broadcast and surveillance equipment.
Communications Receivers
The parallel interface and 60M SPS rate support IF sampling in wireless base stations, improving receiver sensitivity and dynamic range.
Industrial Control Systems
In high-speed industrial sensors, the ADS826E-BB provides fast conversion for real-time monitoring and control in automation lines.
Medical Ultrasound
The high sampling rate allows capture of high-frequency ultrasound echoes, enabling detailed imaging in diagnostic equipment.
Radar Systems
Wide temperature range and high-speed sampling make it suitable for radar signal processing in defense and aerospace applications.
- Q: What is the resolution of the ADS826E-BB?
- A: The ADS826E-BB is a 10-bit analog-to-digital converter.
- Q: What is the sampling rate?
- A: It has a sampling rate of 60 MSPS (60M samples per second).
- Q: How many channels does this ADC have?
- A: It is a single-channel (1 input) ADC.
- Q: What interface does the ADS826E-BB use?
- A: It uses a parallel interface.
- Q: What is the architecture?
- A: It uses a sample-and-hold (S/H) ADC architecture.
- Q: What package is available?
- A: It comes in a 28-SSOP package (0.209", 5.30mm width).
