Texas Instruments ADS850Y/250
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $44.81 | $44.81 |
| 15+ | $43.40 | $651.00 |
| 25+ | $42.45 | $1,061.25 |
| 50+ | $40.09 | $2,004.50 |
| 100+ | $35.38 | $3,538.00 |
| N+ | $7.08 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 10M |
| Number of Inputs | 1 |
| Input Type | Differential, Single Ended |
| Data Interface | Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | Pipelined |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 48-TQFP |
| Supplier Device Package | 48-TQFP (7x7) |
| ROHS |  |
The ADS850Y/250 is a 14-bit, single-channel analog-to-digital converter from Texas Instruments with a 10M SPS sampling rate. It features a S/H-ADC architecture with both external and internal reference options. The parallel interface ensures high-speed data transfer to digital systems. Operating from -40°C to +85°C, this ADC is packaged in a 48-TQFP, making it suitable for industrial control, video digitization, and communication applications requiring fast and accurate conversion.
