Advanced Linear Devices Inc. ALD500ASCL
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $38.28 | $38.28 |
| 15+ | $8.80 | $132.00 |
| 25+ | $8.61 | $215.25 |
| 50+ | $8.13 | $406.50 |
| 100+ | $7.18 | $718.00 |
| N+ | $1.44 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Advanced Linear Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Number of Bits | 17 |
| Sampling Rate (Per Second) | - |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | - |
| Configuration | ADC |
| Ratio - S/H:ADC | - |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | ±5V |
| Voltage - Supply, Digital | ±5V |
| Features | - |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| ROHS |  |
The ALD500ASCL is a high-resolution 17-bit analog-to-digital converter (ADC) from Advanced Linear Devices. Designed for precision measurement applications, it offers a single input channel and operates over a 0°C to 70°C temperature range. This ADC is well-suited for digital multimeters, weigh scales, and scientific instrumentation where high accuracy is paramount. It is available in a 16-SOIC package.
- Ultra-High Resolution: 17-bit resolution provides exceptional measurement precision, ideal for demanding instrumentation.
- High Accuracy: Designed for precision applications, ensuring reliable and repeatable measurements.
- Low Noise: The integrating architecture provides excellent noise rejection, especially for low-frequency signals.
- Stable Performance: Reliable operation over the commercial temperature range of 0°C to 70°C.
High-Precision Measurement Instruments
The 17-bit resolution of the ALD500ASCL makes it ideal for digital multimeters, precision voltmeters, and other laboratory-grade measurement equipment where extremely accurate voltage readings are required.
Weigh Scale and Load Cell Interfaces
In industrial weighing systems, the high resolution allows for precise measurement of small voltage changes from load cells, enabling accurate weight determination even for very small increments.
Thermocouple and RTD Linearization
For temperature measurement, the ALD500ASCL can digitize the small voltages from thermocouples or RTDs with high precision, allowing for accurate temperature readings across a wide range.
Data Acquisition for Scientific Research
In scientific data acquisition systems, the high resolution ensures that subtle signal variations are captured, which is critical for experiments involving physical, chemical, or biological phenomena.
Battery Monitoring Systems
Monitor battery voltage and current with high precision to accurately determine state-of-charge and state-of-health in battery management systems for industrial or backup power applications.
- Q: What is the ALD500ASCL?
- A: It is a high-resolution, single-channel analog-to-digital converter (ADC) from Advanced Linear Devices.
- Q: What is the resolution of the ALD500ASCL?
- A: It offers a high resolution of 17 bits, providing very fine measurement granularity.
- Q: How many input channels does it have?
- A: It has 1 analog input channel.
- Q: What is the architecture of this ADC?
- A: The architecture is listed as 'ADC', which typically refers to an integrating or dual-slope type converter.
- Q: What is the operating temperature range?
- A: It operates over a commercial temperature range of 0°C to 70°C.
- Q: What package is the ALD500ASCL available in?
- A: It is available in a 16-SOIC (0.154", 3.90mm Width) package.
