Diodes Incorporated AS78L05MTR-G1
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.49 | $0.49 |
| 15+ | $0.48 | $7.20 |
| 25+ | $0.47 | $11.75 |
| 50+ | $0.44 | $22.00 |
| 100+ | $0.39 | $39.00 |
| N+ | $0.08 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Diodes Incorporated |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 30V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 1.8V @ 100mA (Typ) |
| Current - Output | 100mA |
| Current - Quiescent (Iq) | 5.5 mA |
| Current - Supply (Max) | - |
| PSRR | 62dB (120Hz) |
| Control Features | - |
| Protection Features | Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| ROHS |  |
The AS78L05MTR-G1 from Diodes Incorporated is a fixed 5V linear regulator delivering up to 100mA. Housed in an 8-SOIC package, it offers a typical dropout of 1.8V and quiescent current of 5.5mA. With 62dB PSRR at 120Hz, it provides clean, stable power for noise-sensitive applications.
- Stable 5V Output: Fixed 5V regulation with 62dB ripple rejection ensures clean power for analog and digital circuits.
- Compact SOIC-8 Package: Industry-standard footprint simplifies PCB layout and reduces board space.
- 100mA Current Capability: Sufficient for low-power MCUs, sensors, and interface ICs.
- Low Quiescent Current (5.5mA): Helps minimize power draw in always-on applications.
Industrial Logic Power
Provides a clean 5V rail for microcontrollers and logic ICs in industrial controllers, with 62dB PSRR at 120Hz filtering mains ripple.
Audio Bias Supplies
Low-noise 5V output suitable for biasing op-amps or codecs in audio equipment, leveraging the 62dB ripple rejection.
Metering and Instrumentation
Stable reference voltage for analog measurement circuits in panel meters, ensuring consistent ADC readings.
Home Appliance Control Boards
Reliable 5V supply for sensor interfaces and display drivers in appliances, with thermal protection inherent to LDO design.
Battery-Powered Backup Systems
Regulates battery output to 5V for backup memory or RTC circuits, with 100mA capacity for small loads.
Automotive Body Electronics
Powers CAN transceivers or sensor modules in 12V automotive environments, stepping down with adequate dropout margin.
- Q: What is the output voltage of the AS78L05MTR-G1?
- A: The fixed output voltage is 5V.
- Q: What is the maximum output current?
- A: It can deliver up to 100mA.
- Q: What is the input voltage range?
- A: The input voltage is 5V (typical operating condition; refer to datasheet for absolute max).
- Q: What is the dropout voltage?
- A: Typical dropout is 1.8V at 100mA load.
- Q: What is the quiescent current?
- A: Quiescent current is 5.5mA.
- Q: What package is available?
- A: It comes in an 8-SOIC package.
