Analog Technologies ATDC2934
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $6.08 | $6.08 |
| 15+ | $5.89 | $88.35 |
| 25+ | $5.76 | $144.00 |
| 50+ | $5.44 | $272.00 |
| 100+ | $4.80 | $480.00 |
| N+ | $0.96 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Technologies |
| Product Series | |
| Packaging | Strip | |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 5V |
| Voltage - Input (Max) | 42V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Voltage - Output (Max) | 20V |
| Current - Output | 600mA |
| Frequency - Switching | 1.2MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 |
| Supplier Device Package | SOT-23-6 |
| ROHS |  |
The ATDC2934 from Analog Technologies is a high-efficiency, 600mA synchronous Buck (step-down) DC-DC converter. It accepts a wide input voltage from 5V to 42V and provides an adjustable output from 0.8V to 20V. Operating at a fixed 1.2MHz switching frequency, it enables the use of small, low-cost external components. Its compact SOT-23-6 package makes it an excellent choice for space-limited applications requiring reliable power conversion.
- Wide Input Range (5V-42V): Handles a variety of power sources, from 5V USB to 42V industrial rails, providing design flexibility.
- High Switching Frequency (1.2MHz): Reduces external inductor and capacitor sizes, saving PCB space and BOM cost.
- Compact SOT-23-6 Package: Ideal for space-constrained designs in portable and embedded applications.
- Adjustable Output (0.8V-20V): Provides versatility to power a wide range of loads from logic to analog circuits.
Battery-Powered Devices
With a wide 5V to 42V input range and high efficiency at light loads, the ATDC2934 is ideal for extending battery life in portable instruments and industrial handhelds.
Industrial Sensors
Its 1.2MHz fixed frequency allows for small external components, making it suitable for space-constrained industrial sensor modules requiring a stable 3.3V or 5V rail from a 24V bus.
Automotive Accessories
The 42V input tolerance handles load dump transients in 12V automotive systems, providing a regulated supply for infotainment or telematics peripherals.
Networking Equipment
For routers and switches, the ATDC2934 efficiently steps down 12V or 24V rails to lower voltages for control logic and interface circuits.
Home Automation
In smart home hubs, this buck converter delivers a clean, regulated output from various DC adapters, ensuring reliable operation of microcontrollers and wireless modules.
- Q: What type of converter is the ATDC2934?
- A: The ATDC2934 is a Buck (step-down) DC-DC converter.
- Q: What is the input voltage range?
- A: The input voltage range is 5V to 42V.
- Q: What is the output voltage range?
- A: The output voltage is adjustable from 0.8V to 20V.
- Q: What is the maximum output current?
- A: The maximum output current is 600mA.
- Q: What is the switching frequency?
- A: The switching frequency is fixed at 1.2MHz.
- Q: What package is available?
- A: It is available in a compact SOT-23-6 package.
