Analog Technologies, Inc. ATI2934
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $3.56 | $3.56 |
| 15+ | $0.82 | $12.30 |
| 25+ | $0.80 | $20.00 |
| 50+ | $0.76 | $38.00 |
| 100+ | $0.67 | $67.00 |
| N+ | $0.13 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Technologies, Inc. |
| Product Series | |
| Packaging | Strip | |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 5V |
| Voltage - Input (Max) | 42V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Voltage - Output (Max) | 20V |
| Current - Output | 600mA |
| Frequency - Switching | 1.2MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 |
| Supplier Device Package | SOT-23-6 |
| ROHS |  |
The ATI2934 is a robust Buck DC-DC converter from Analog Technologies, Inc. It accepts a wide input voltage from 5V to 42V and provides an adjustable output from 0.8V to 20V at up to 600mA. Operating at 1.2MHz, it enables compact external components. This converter is well-suited for automotive, industrial, and networking applications where wide input voltage variations are common. The SOT-23-6 package is compact and easy to integrate.
- Wide Input Voltage: 5V-42V input range handles automotive and industrial power rails with transients.
- Adjustable Output: Output from 0.8V to 20V provides flexibility for various load requirements.
- Compact Package: SOT-23-6 package minimizes board space in space-constrained designs.
- High Frequency: 1.2MHz switching reduces external component sizes, lowering overall solution cost.
Automotive Power Supplies
The ATI2934 is designed for automotive applications with a wide 5V-42V input range. It can step down from a 12V or 24V vehicle battery to power ECUs, sensors, and infotainment systems at up to 600mA.
Industrial Control Systems
In industrial environments with 24V or 48V rails, this buck converter provides a regulated low-voltage supply for microcontrollers, PLCs, and communication interfaces. The wide input range handles voltage transients.
Networking Equipment
For networking devices powered from 12V or 24V, the ATI2934 generates stable 3.3V or 5V rails. Its 1.2MHz frequency allows for small inductors, saving space in dense PCB layouts.
LED Lighting Drivers
With an adjustable output up to 20V, this converter can drive LED strings in automotive or industrial lighting. The 600mA current capability suits medium-power LED applications.
Battery Charging Circuits
The wide input range makes it suitable for charging circuits powered from various sources. It can step down higher voltages to charge batteries or power downstream regulators.
- Q: What type of converter is the ATI2934?
- A: It is a Buck (step-down) DC-DC converter.
- Q: What is the input voltage range?
- A: The input voltage range is 5V to 42V.
- Q: What is the output voltage range?
- A: The adjustable output voltage ranges from 0.8V to 20V.
- Q: What is the maximum output current?
- A: The maximum output current is 600mA.
- Q: What is the switching frequency?
- A: The switching frequency is 1.2MHz.
- Q: What package is available?
- A: It comes in a SOT-23-6 package.
