Microchip Technology ATMEGA8535-16MUR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $3.49 | $3.49 |
| 15+ | $3.38 | $50.70 |
| 25+ | $3.30 | $82.50 |
| 50+ | $3.12 | $156.00 |
| 100+ | $2.75 | $275.00 |
| N+ | $0.55 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | AVR® ATmega |
| Packaging | Cut Tape (CT) | NULL |
| Core Processor | AVR |
| Core Size | 8-Bit |
| Speed | 16MHz |
| Connectivity | I2C, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 32 |
| Program Memory Size | 8KB (4K x 16) |
| Program Memory Type | FLASH |
| EEPROM Size | 512 x 8 |
| RAM Size | 512 x 8 |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Data Converters | A/D 8x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 44-VQFN (7x7) |
| Package / Case | 44-VFQFN Exposed Pad |
| ROHS |  |
The ATMEGA8535-16MUR from Microchip Technology is an 8-bit AVR microcontroller delivering 16MHz performance in a compact 44-VFQFN package. It features 8KB flash memory, 512B SRAM, and operates from 4.5V to 5.5V. Built-in brown-out detection, power-on reset, PWM, and watchdog timer ensure dependable operation in industrial and consumer environments.
- High-speed 16MHz AVR core: Enables fast processing for real-time applications.
- Robust 5V operation: Simplifies interfacing with legacy analog and digital peripherals.
- Integrated safety features: Brown-out detect and WDT improve system reliability.
- Compact 44-VFQFN package: Saves board space for space-constrained designs.
Industrial Control Systems
With 8KB flash and 512B RAM, it handles real-time control loops at 16MHz, ideal for motor control and process automation.
Automotive Aftermarket
Operates from 4.5V to 5.5V, compatible with standard automotive power rails, suitable for sensor interfaces and dashboard modules.
Smart Sensor Nodes
Integrated POR and Brown-out Detect ensure reliable startup in battery-backed sensor applications, while PWM supports signal conditioning.
Consumer Appliances
The 44-VFQFN package enables compact PCB designs for white goods, with WDT enhancing system robustness against firmware hangs.
Embedded Education
AVR architecture with 16MHz speed provides a balanced platform for teaching microcontroller fundamentals and prototyping.
Power Management Units
5V operation simplifies interfacing with analog front-ends, and the PWM module allows precise control of switching regulators.
- Q: What is the operating voltage range?
- A: 4.5V to 5.5V.
- Q: What is the maximum clock speed?
- A: 16MHz.
- Q: How much flash memory is available?
- A: 8KB (4K x 16).
- Q: What package is this available in?
- A: 44-VFQFN Exposed Pad.
- Q: Does it include a watchdog timer?
- A: Yes, WDT is included.
